R-775(W)R-785(AL) - 41
Note: The parts marked "∆" may cause undue microwave exposure. / The parts marked "*" are used in
voltage more than 250V. / "§" Mark: Spare parts delivery section
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
PARTS LIST
*
∆*
*
*
ELECTRIC PARTS
C RC-QZA240WRE0 U High voltage capacitor 1 AR
F1 QFS-BA009WRE0 U Fuse 20A 1 AC
F2 QFS-CA025WRE0 U Fuse F8A 1 AC
FM RMOTEA361WRE0 U Fan motor 1 AT
GH1 RHET-A254WRZZ U Top grill heating element 1 AT
GH2 RHET-A248WRZ1 U Bottom grill heating element 1 AW
MG RV-MZA243WRE1 U Magnetron 1 BH
OL RLMPTA066WRE0 U Oven lamp 1 AK
SW1 QSW-MA146WRZZ J Monitored latch switch 1 AC
SW2 QSW-MA147WRZZ J Stop switch 1 AG
SW3 QSW-MA146WRZZ J Monitor switch 1 AC
T RTRN-A019URE0 U High voltage transformer 1 BF
TC1 RTHM-A098WRE0 U Thermal cut-out 125˚C off (MG) 1 AH
TC2 RTHM-A124WRZZ U Thermal cut-out 145˚C off 115˚C on (OVEN) 1 AH
TTM RMOTDA227WRE0 U Turntable motor 1 AU
1- 1 FPWBFA309WRE2 U Noise filter 1 AT
1- 2 RTRN-A529WRE0 U TC transformer 1 AV
1- 3 QACCVA004URE2 U Power supply cord 1 AQ
1- 4 FH-DZA035WRE0 U High voltage rectifier assembly 1 AP
CABINET PARTS
2- 1 GCABDA083WRP1 U Back plate 1 AN
2- 2 GLEGPA028WRE0 U Foot 2 AA
2- 3 GCABUW468URT0 U Outer case cabinet [R-775(W)] 1 AX
2- 3 GCABUW045URP0 U Outer case cabinet [R-785(AL)] 1 AY
2- 4 GDAI-A002URP0 U Base plate 1 AR
CONTROL PANEL PARTS
3- 1 DPWBFA185URK0 U Power unit 1 BC
3- 1A QCNCMA412DRE0 U 4-pin connector (CN-A) 1 AD
3- 1B QCNCMA414DRE0 U 2-pin connector (CN-B) 1 AB
3- 1C FW-VZA266DRZZ U 15-pin harness (WH-1) 1 AE
3- 1D QCNCMA230DRE0 U 4-pin connector (CN-E) 1 AC
C1 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C2 VCEAG31VW108M U Capacitor 1000 uF 35V 1 AE
C3 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C4-5 VCEAG31VW106M U Capacitor 10 uF 35V 2 AB
D1-6 VHD1SS270A/-1 U Diode (1SS270A) 6 AA
D11-14 VHD1N4005E/-2 U Diode bridge (1N4005E) 4 AA
D11-14 VHD1N4004S/-1T U Diode bridge (1N4004S)(Interchange angle) 4 AA
Q2 VSKTA1274//-3 U Transistor (KTA1274) 1 AA
Q3 VSKRC243M//-3 U Transistor (KRC243M) 1 AB
R2 VRD-B12EF152J U Resistor 1.5K ohm 1/4W 1 AA
R3-4 VRS-B13AA511J U Resistor 510 ohm 1W 2 AB
R5 VRD-B12EF332J U Resistor 3.3K ohm 1/4W 1 AA
R6 VRS-B13AA201J U Resistor 200 ohm 1W 1 AA
RY1 RRLY-A117DRE0 U Relay (DU18D1-1P(M)-R) 1 AG
RY2 RRLY-A122DRE0 U Relay (DU18D1-1P(M)-R-S) 1 AG
RY3-4 RRLY-A113DRE0 U Relay (DU24D1-1P(M)-R) 2 AG
RY5-6 RRLY-B004MRE0 U Relay (FTR-F3AA024E) 2 AL
SP1 RALM-A014DRE0 U Buzzer (PKM22EPT) 1 AG
VRS1 RH-VZA034DRE0 U Varistor (10G471K) 1 AD
ZD2 VHEHZ201///-1 U Zener diode (HZ20-1) 1 AB
3 DPNLCA140URK0 U C/P assy [R-785(AL)] 1 AY
3 DPNLCW082URK0 U C/P assy [R-775(W)] 1 AY
3- 2 DPWBFC234WRKZ U CPU unit 1 BC
3- 3 FPWBFA060URK0 U Jog switch unit 1 AS
3- 3-1 FW-VZA277DREZ U 13-pin harness (CN-J) 1 AE
3- 3-2 RVR-BA014DRE0 U Potentiometer (VR1) 1 AD
3- 3-3 RVR-BA018WRE0 U Rotary encoder (RSW1) 1 AH
3- 3-4 QSW-K0005AWZZT U Tact switch (SW1 - SW13) 13 AD
3- 4 LHLD-A007URF1 U LCD holder 1 AD
3- 5 PSHEPA647WRE0 U LCD sheet 1 AL
3- 6 GMADIA038URR0 U Display window 1 AH
3- 7 HPNLCA120URR0 U Control panel [R-785(AL)] 1 AQ
3- 7 HPNLCW074URR0 U Control panel [R-775(W)] 1 AQ
3- 8 JBTN-O016URF0 U Express pizza button 1 AE
3- 9 JBTN-A102URT0 U Auto cook button [R-785(AL)] 1 AP
3- 9 JBTN-W031URF0 U Auto cook button [R-775(W)] 1 AD
3- 10 JBTN-A103URT0 U Stop/Watt button [R-785(AL)] 1 AP
3- 10 JBTN-W032URF0 U Stop/Watt button [R-775(W)] 1 AD
3- 11 JBTN-A104URT0 U More/Less button 1 AW
3- 12 JKNBKA041URT0 U Vari knob [R-785(AL)] 1 AE
3- 12 JKNBKW012URF0 U Vari knob [R-775(W)] 1 AE
3- 13 JKNBKA043URT0 U Timer knob [R-785(AL)] 1 AE
3- 13 JKNBKW014URF0 U Timer knob [R-775(W)] 1 AE
3- 14 MSPR-A002URE0 U Spring 1 AB
3- 15 XEPSD30P10XS0 U Screw : 3mm x 10mm 12 AA
∆
∆
