This document describes the Sharp SF-2022 electrostatic copying machine, a modularly designed copier offering high copy productivity and convenient features.

Function Description

The Sharp SF-2022 is a desktop electrostatic transfer system designed for dry copying. It supports various copying modes including normal copying, reduction/enlargement/zoom, dual page copying, edge erase, margin shift, special papers (manual feed), two-sided copying, single-color copying, interrupting a copy run, automatic exposure adjustment, and toner save mode.

Important Technical Specifications

General:

Copy System: Dry, electrostatic transfer system
Originals: Sheets, bound documents
Original Size: Max. A3 (11" x 17")
Copy Sizes: Max. A3 (11" x 17"), min. A6 (8-1/2" x 5-1/2")
Copying Speed (at 100% copy ratio):
- 22 copies/min. (A4 (8-1/2" x 11"))
- 14 copies/min. (B4 (8-1/2" x 14"))
- 12 copies/min. (A3 (11" x 17"))
Continuous Copy: Max. 99 copies; subtractive counter
First Copy Time: 4.1 sec.
Warm-up Time: Approx. 90 sec.
Copy Ratio: Variable 50% to 200% in 1% increments (total 151 steps); Fixed ratios include 100%, 86%, 81%, 70%, 50%, 115%, 122%, 141%, 200% (100%, 95%, 77%, 64%, 50%, 121%, 129%, 141%, 200%)
Exposure System: Moving optical source, slit exposure (stationary platen) with automatic exposure function
Copy Paper Feed: One paper drawer with automatic feed (500 sheets) or two paper drawers with automatic feed (500 sheets each); manual feed tray with 50-sheet automatic feed capability
Fusing System: Heat rollers
Developer System: Magnetic brush development
Light Source: Halogen lamp
Power Supply: Local voltage ±10%
Power Consumption: Max. 1.5 kW
Weight (with optional document cover SF-CV13):
- Approx. 62.1 kg (137 lbs.)
- Approx. 66 kg (145.6 lbs.) (with 500-sheet paper drawer)
- Approx. 70 kg (154.4 lbs.) (with duplex module)
Copier Dimensions (with optional document cover SF-CV13): 633(W) x 650(D) x 607(H) mm (24-59/64"(W) x 25-19/32"(D) x 23-29/32"(H))

Optional Equipment:

Document Cover (SF-CV13)
Automatic Document Feeder (SF-A14):
- Acceptable Originals: Weight 50 to 128 g/m² (14 to 34 lbs.); Size A5 to A3 (8-1/2" x 5-1/2" to 11" x 17"); Up to 50 sheets for A5, A4, B4 and A3 (8-1/2" x 5-1/2", 8-1/2" x 11", 8-1/2" x 14" and 11" x 17"), provided the total aggregate thickness does not exceed 6.5 mm or 1/4" (50 to 80 g/m² or 14 to 20 lbs.) or 5 mm or 3/16" (80 to 128 g/m² or 21 to 34 lbs.).
- Power Supply: Drawn from the copier.
Reversing Automatic Document Feeder (SF-A54):
- Acceptable Originals: Weight 50 to 128 g/m² (14 to 34 lbs.) for single-sided original; 50 to 128 g/m² (14 to 34 lbs.) for two-sided original. Size A5 to A3 (8-1/2" x 5-1/2" to 11" x 17"). Number: Up to 50 sheets for A5, A4, B4 and A3 (8-1/2" x 5-1/2", 8-1/2" x 11", 8-1/2" x 14" and 11" x 17"), provided the total aggregate thickness does not exceed 6.5 mm or 1/4" (50 to 80 g/m² or 14 to 20 lbs.) or 5 mm or 3/16" (80 to 128 g/m² or 21 to 34 lbs.). Up to 30 sheets for A3 (11" x 17").
- Power Supply: Drawn from the copier.
10-Bin Sorter (SF-S14):
- No. of Bins: 10
- Bin Capacity: NON-SORT: 100 sheets (top bin); SORT: 50 sheets (A4), 40 sheets (B4), 30 sheets (A3); GROUP: 35 sheets (A4), 25 sheets (B4), 20 sheets (A3).
- Paper Size: Top bin: Max. A3, Min. A6; Sort bins: Max. A3, Min. A5.
- Power Supply: Drawn from the copier.
20-Bin Sorter (SF-S15):
- No. of Bins: 20
- Bin Capacity: NON-SORT: 100 sheets (top bin); SORT: 50 sheets; GROUP: 30 sheets.
- Paper Size: Top bin: Max. A3, Min. A6; Sort bins: Max. A3, Min. B5.
- Power Supply: Drawn from the copier.
20-Bin Staple Sorter (SF-S52):
- No. of Bins: 20
- Bin Capacity: NON-SORT: 100 sheets (top bin); SORT: 35 sheets (A4), 25 sheets (B4), 15 sheets (A3); STAPLE SORT: 25 sheets (A4 and B4), 15 sheets (A3); GROUP: 25 sheets (A4), 20 sheets (B4), 10 sheets (A3).
- Paper Size: Top bin: Max. A3, Min. A6; Sort bins: Max. A3, Min. B5.
- Stapling Capacity: 25 sheets (80 g/m² (20 lbs.))
- Power Supply: Drawn from the copier.
Stand/500-Sheet Paper Drawer (SF-D20):
- Paper Size: A4 to A3 (8-1/2" x 11" to 11" x 17")
- Paper Capacity: 500 sheets of paper. Total of 1,000 sheets of paper with an optional 500-sheet paper drawer installed.
Stand/1000-Sheet Paper Drawer (SF-D21):
- Paper Size: A4 to B4 (8-1/2" x 11" to 8-1/2" x 14")
- Paper Capacity: 1,000 sheets of paper. Total of 1,500 sheets of paper with an optional 500-sheet paper drawer installed.
Duplex Module (SF-DM11)
500-Sheet Paper Drawer (SF-CM11)
Personal Counter (SF-71A/71B)
Cassette (SF-IC11)
Card Counter (SF-EA11)
Auditor (SF-EA12)
Counter Commander (SF-EA13)

Usage Features

Getting Started:

Installation: Proper installation is crucial to avoid damage. The copier should be placed on a firm, level surface, away from damp, humid, or dusty environments, direct sunlight, and extreme temperature changes. Adequate ventilation is required, with at least 10 cm (4 inches) from any wall and 33 cm (13 inches) from adjacent right walls.
Power Switch: The "POWER" switch positions are marked "I" for ON and "O" for OFF. If the copier is in stand-by, it is de-energized but not completely off. For complete electrical disconnection, pull out the main plug.
Paper Types and Sizes:
- Ordinary Paper: Can be fed automatically from paper drawers (max. 50 sheets) or manually (single sheet feed).
  - Automatic Feed: A5 (8-1/2" x 5-1/2") to A3 (11" x 17"), weights 56 g/m² (15 lbs.) to 80 g/m² (21 lbs.). A5 paper can be set in the lower paper drawer with an optional inner cassette.
  - Manual Feed: A6 (8-1/2" x 5-1/2") to A3 (11" x 17"), weights 52 g/m² (14 lbs.) to 128 g/m² (34 lbs.). A4 (8-1/2" x 11") is the maximum size for manually fed paper weighing from 104 to 128 g/m² (28 to 34 lbs.).
- Special Papers: Transparency films, labels, and tracing paper must be fed manually through the manual feed tray.
Loading Copy Paper:
- 500-Sheet Paper Drawer: Gently lift and draw out the drawer, fan the copy paper, insert it, and push the drawer firmly back. The drawer holds 500 sheets, and paper should not load above the maximum height line.
- Lower Paper Drawer (with inner cassette): Gently lift and draw out the lower paper drawer. Grasp the inner cassette tabs and remove it. Remove the cover of the inner cassette, fan the copy paper, and place it in the cassette. Position the inner cassette so its four protrusions fit into the holes of the paper drawer. Inner cassettes are available for five different paper sizes: A5, A4, A4R, B4, and A3. Place the paper size plate in front of the paper drawer to match the paper size set. Push the lower paper drawer firmly back into the copier.
Adding Toner: The toner required indicator blinks when toner is needed. Open the front cover, tap the side of the toner cartridge several times, press down on the lever to pull out the cartridge, shake the new toner cartridge, and install it. While holding the toner cartridge, pull out the toner sealing tape and close the front cover.

Making Copies:

Normal Copying:
1. Turn on the power switch.
2. Place the original face down on the document glass, aligning it with the original size scale, and close the document cover.
3. Press the CASSETTE SELECT key to select the desired paper size.
4. Adjust copy density: Automatic exposure is default; for manual adjustment, press AUTO/MANUAL/PHOTO to select MANUAL and use LIGHT/DARK keys. For photographs, select PHOTO and adjust with LIGHT/DARK keys.
5. Set the copy number (default is "0" for a single copy).
6. Press the print button.
Reduction/Enlargement/Zoom:
- Automatic: Place original, press ORIGINAL SIZE ENTER, select paper size with CASSETTE SELECT, then press AUTO IMAGE. The copy ratio will be automatically set.
- Manual: Place original, press reduction/enlargement/ZOOM keys. Preset reduction ratios (AB: 86%, 81%, 70%, 50%; Inches: 95%, 77%, 64%, 50%) and enlargement ratios (AB: 115%, 122%, 141%, 200%; Inches: 121%, 129%, 141%, 200%) are available. ZOOM keys allow 1% increments from 50% to 200%.
Dual Page Copying: Place two originals side-by-side on the document glass, aligned with the paper size index. Press DUAL PAGE COPY key.
Edge Erase: Erases dark areas from copy edges. Place original, press EDGE ERASE key, select paper size, set copy number, and press print.
Margin Shift: Shifts text/images to leave a binding margin. Set original, press MARGIN SHIFT key, proceed with copying.
Special Papers (Manual Feed): Open manual feed tray, extend tray for larger papers, set feed tray guides to paper width, insert paper, set copy number, and press print.
Two-Sided Copying:
- Manual Feed Tray: Place first original, make copy. Replace with second original. Turn first copy over side to side and place on manual feed tray. Press print.
- SIMPLEX TO DUPLEX Key (with duplex module): Place first original face down on document glass. Press SIMPLEX TO DUPLEX key to select EVEN NUMBER. Select paper size. Set copy number. Press print. Set second original and press print again.
Single Colour Copying: Install desired color developer unit. Set original, select desired copier functions, and press print. To copy with an additional color, change the developer unit and feed the copy from step 2 above.
Interrupting a Copy Run: Press INTERRUPT key. When copier stops, set new original. Select desired functions, set copy number, press print. When finished, press INTERRUPT key again.
Automatic Exposure Adjustment: Check copier is in AUTO exposure mode. Open front cover. Press AUTO/MANUAL/PHOTO key for approx. 3 seconds. Press LIGHT or DARK key to lighten or darken the automatic exposure level.
Toner Save Mode: Press AUTO/MANUAL/PHOTO key to select PHOTO mode. Open front cover. Press AUTO/MANUAL/PHOTO key for approx. 3 seconds. Press LIGHT key until "1" EXPOSURE indicator lights.

Status Indicators:

Misfeed Removal: The misfeed indicator blinks when a misfeed occurs. Follow instructions for removal from manual feed tray, paper drawer, transport area, fusing and exit area, or duplex module.
Used Toner Disposal: The toner collecting container full indicator blinks when full. Open cover, turn locking lever, remove container, replace with new one, and close cover.
Developer Required: The developer replacement required indicator lights when replacement is needed. Contact service.
Maintenance Required: The maintenance required indicator lights when service is needed. Contact service.

Optional Equipment Usage:

Automatic Document Feeder (SF-A14) / Reversing Automatic Document Feeder (SF-A54):
- Normal Copying: Set original(s) on ADF tray face down (ADF) or face up (RADF) with guides adjusted. The ORIGINAL SIZE indicator will light. Select desired copier functions, set copy number, and press print.
- Duplex Copying of Single-Sided Originals (ADF/RADF): Count originals. Set originals face down (ADF) or face up (RADF) on tray. Press SIMPLEX TO DUPLEX key to select EVEN NUMBER or ODD NUMBER. Select paper size. Set copy number, press print.
- Copying Two-Sided Originals (RADF): Set two-sided original(s) face up on RADF tray, adjust guides. Press DUPLEX key. Select paper size. Set copy number, press print.
10-Bin Sorter (SF-S14) / 20-Bin Sorter (SF-S15):
- Sorting Modes: NON-SORT (copies to top bin), SORT (automatic collating to sort bins), GROUP (all copies of same original to same bin). Select mode with SORTER key.
20-Bin Staple Sorter (SF-S52):
- Staple Sort Mode: Set original on document glass (corner to be stapled to upper right) or ADF/RADF tray (stapling position in upper right for ADF, upper left for RADF). Press SORTER key to select STAPLE SORT mode. Set copy number. Press print. When finished, press manual staple key.
Stand/500-Sheet Paper Drawer (SF-D20) / Stand/1000-Sheet Paper Drawer (SF-D21):
- Loading Paper: Gently lift and draw out the drawer, fan paper, insert it, and push the drawer firmly back.

Maintenance Features

User Maintenance:
- Document Glass and Document Cover: Wipe with a soft, clean cloth. If necessary, dampen cloth with water. Do not use thinner, benzene, or similar volatile cleaning agents.
Copier Trouble (Troubleshooting Guide):
- Copier does not operate: Check if plugged in, power switch ON, READY indicator off (warming up), paper required, toner required, misfeed occurred, or toner collecting container full.
- Copies are too dark or too light: Adjust copy density.
- Blank copies: Place original face down on document glass.
- Copies smear if rubbed: Paper too heavy, paper damp, original smudged/blotchy.
- Paper misfeeds frequently: Non-standard paper used, paper drawers not properly installed, pieces of paper inside copier, paper curled or damp.
- Dust, dirt, smudges appear on copies: Document glass/cover dirty, original smudged/blotchy.
- Developer/Maintenance Required: If developer replacement or maintenance indicators are on, contact Sharp Service Centre.
Self-Diagnostic Function: The SF-2022 has an automatic self-diagnostic function that will display an alphanumeric code on the copy quantity display if a malfunction occurs.
- "CH" light: Indicates a cover is open or developer unit is not installed.
- Other codes: Contact Sharp Service Centre.
Supplies and Storage: Store SF-2022 supplies (paper, toner, toner collecting container) in a dry, even temperature, clean place, not exposed to direct sunlight. Store copy paper flat in its wrapper.
