CHAPTER 8. OTHER
[1] Service tools
1. List
1.1. Extension board unit
NO. PARTS CODE DESCRIPTION Q'TY
PRICE
RANK
1 CPWBF3201SCS1 Extension board unit (TEL/LIU PWB) 1 BA
2 PSHEZ3579SCZZ Shading wave memory standard paper 1 AD
NO. PARTS CODE DESCRIPTION Q'TY
PRICE
RANK
1 QCNWG471BSCZZ SPEAKER RELAY CABLE 1 AN
2 QCNWG206BSCZZ PANEL RELAY CABLE 1AT
3 QCNWG202BSCZZ CIS RELAY CABLE 1AN
4 QCNWG205BSCZZ HEAD RELAY CABLE 1AS
5 QCNWG204BSCZZ CAM SWITCH RELAY CABLE 1 AG
6 QCNWG242BSCZZ MOTOR RELAY CABLE 1AM
7 QCNWG201BSCZZ SENSOR RELAY CABLE 1BB
8 VRS-RE3AA122J RESISTOR (1W 1.2KΩ ±5%)[R30] 1 AC
9 VHPSG206S//-1 PHOTO TRANSISTOR [PH1] 1 AG
10 VHPSG206S//-1 PHOTO TRANSISTOR [PH2] 1 AG
TEL/LIU PWB
PH2
PH1
R30
TP3
DG
(ORANGE)
TP4
+24VL
(YELLOW)
CE
K
A
TP1
PIN
(BROWN)
TP2
FILM
(RED)
K
A
C
E
