Sharp VC-V50S - Page 65

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
VC-V50S
VC-V80T
VC-V91T
73
SC602 QSOCZ0293GEZZ J Socket, 2 Pin AC
SC701 QSOCN0704REN1 V Socket, 7 Pin AB
SC702 QSOCZ0292GEZZ J Socket, 2 Pin AC
SC6101 QSOCN0595REZZ V Socket, 5 Pin(V91T) AB
W803 LHLDZ1962AJ00 V Holder AD
W804 LHLDZ1962AJ00 V Holder AD
DUNTK5791TEV1(VC-V50S)
DUNTK5791TEV3(VC-V80T/V91T)
OPERATION UNIT
LED’S
D8101 RH-PX0008AJZZ V LED AC
D8102 RH-PX0008AJZZ V LED AC
D8103 RH-PX0008AJZZ V LED AC
D8104 RH-PX0008AJZZ V LED AC
D8105 RH-PX0008AJZZ V LED AC
D8106 RH-PX0008AJZZ V LED AC
D8107 RH-PX0008AJZZ V LED AC
D8108 RH-PX0008AJZZ V LED AC
D8111 RH-PX0009AJZZ V LED AC
D8112 RH-PX0009AJZZ V LED AC
RESISTORS
R8101 VRS-CY1JF391J V 390 1/16W Metal Oxide AA
R8102 VRS-CY1JF391J V 390 1/16W Metal Oxide AA
R8103 VRS-CY1JF391J V 390 1/16W Metal Oxide AA
R8104 VRS-CY1JF391J V 390 1/16W Metal Oxide AA
R8105 VRS-CY1JF391J V 390 1/16W Metal Oxide AA
R8106 VRS-CY1JF391J V 390 1/16W Metal Oxide AA
R8107 VRS-CY1JF391J V 390 1/16W Metal Oxide AA
R8108 VRS-CY1JF391J V 390 1/16W Metal Oxide AA
R8111 VRS-CY1JF391J V 390 1/16W Metal Oxide AA
R8112 VRS-CY1JF391J V 390 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
SC8101 QSOCN0798REZZ V Socket, 7 Pin(V50S) AF
SC8101 QSOCN0998REZZ V Socket, 9 Pin(V80T/V91T) AD
DUNTK5792TEV1(VC-V91T)
LED UNIT
VARIABLE RESISTORS
R6701 RVR-B4372GEZZ J Variable Resistor AD
R6702 RVR-B4372GEZZ J Variable Resistor AD
MISCELLANEOUS PART
SC6701 QSOCN0596REZZ V Socket, 5 Pin AB
R6172 VRS-CY1JF564J V 560k 1/16W Metal Oxide AA
(V91T)
R6175 VRS-CY1JF000J V 0 1/16W Metal Oxide AA
(V91T)
R6176 VRS-CY1JF472J V 4.7k 1/16W Metal Oxide AA
(V91T)
R6177 VRS-CY1JF563J V 56k 1/16W Metal Oxide AA
(V91T)
R6178 VRS-CY1JF472J V 4.7k 1/16W Metal Oxide AA
(V91T)
R6179 VRS-CY1JF682J V 6.8k 1/16W Metal Oxide AA
(V91T)
R6180 VRS-CY1JF152J V 1.5k 1/16W Metal Oxide AA
(V91T)
R6181 VRS-CY1JF684J V 680k 1/16W Metal Oxide AA
(V91T)
R6182 VRS-CY1JF563J V 56k 1/16W Metal Oxide AA
(V91T)
R6184 VRS-CY1JF153J V 15k 1/16W Metal Oxide AA
(V91T)
R6185 VRS-CY1JF681J V 680 1/16W Metal Oxide AA
(V91T)
R6186 VRS-CY1JF152J V 1.5k 1/16W Metal Oxide AA
(V91T)
R6189 VRS-CY1JF153J V 15k 1/16W Metal Oxide AA
(V91T)
R6190 VRS-CY1JF563J V 56k 1/16W Metal Oxide AA
(V91T)
R6319 VRS-CY1JF123J V 12k 1/16W Metal Oxide AA
(V80T/V91T)
R6329 VRS-CY1JF000J V 0 1/16W Metal Oxide AA
(V80T/V91T)
BALUNES
FB201 RBLN-0043CEZZ V Balun, BLN-0043CE AB
FB202 RBLN-0043CEZZ V Balun, BLN-0043CE AB
FB203 RBLN-0043CEZZ V Balun, BLN-0043CE AB
FB204 RBLN-0043CEZZ V Balun, BLN-0043CE AB
FB702 RBLN-0091GEZZ~ J Balun, BLN-0091GE~ AB
FB801 RBLN-0043CEZZ V Balun, BLN-0043CE AB
FB802 RBLN-0043CEZZ V Balun, BLN-0043CE AB
FB901 RBLN-0043CEZZ V Balun, BLN-0043CE AB
FB902 RBLN-0043CEZZ V Balun, BLN-0043CE AB
FB903 RBLN-0043CEZZ V Balun, BLN-0043CE AB
SWITCHES
S201 QSW-S0274GEZZ J Switch AE
S801 QSW-K0086GEZZ J Switch, Operate AC
S802 QSW-K0086GEZZ J Switch, Stop/Eject AC
S803 QSW-K0086GEZZ J Switch, Play AC
S804 QSW-K0086GEZZ J Switch, FF AC
S805 QSW-K0086GEZZ J Switch, Rew AC
S806 QSW-K0086GEZZ J Switch, Pause/Still AC
S807 QSW-K0086GEZZ J Switch, Rec AC
S808 QSW-K0086GEZZ J Switch, S.S. Picture AC
S811 QSW-S0277GEZZ J Switch, PAL Auto/PAL/ AF
MESECAM/NTSC
MISCELLANEOUS PARTS
å FH901 QFSHD1013CEZZ V Fuse Holder AC
å FH902 QFSHD1014CEZZ V Fuse Holder AC
å F901 QFS-C2025CEZZ V Fuse, T2AL 250V AD
J203 QJAKH0005AJZZ V Jack(V50S) AL
J203 QJAKL0004AJZZ V Jack(V80T/V91T) AM
J6101 QJAKE0231GEZZ J Jack, Mic1(V91T) AG
J6102 QJAKE0231GEZZ J Jack, Mic2(V91T) AG
å PDA901 PRDAF5023AJFW V Heat Sink, Q901 AD
P201 QPLGN0447REZZ V Plug, 4 Pin AA
P702 QPLGN0247REZZ V Plug, 2 Pin AA
P802 QPLGZ0883GEZZ J Plug, 8 Pin AD
P803 QPLGN0759REZZ V Plug, 7 Pin(V50S) AC
P803 QPLGN0959REZZ V Plug, 9 Pin(V80T/V91T) AC
å P901 QPLGN0269GEZZ J Plug, 3 Pin AB
RMC801 RRMCU0062GEZZ J Remote Receiver AG
SC301 QSOCN0464REZZ V Socket, 4 Pin(V50S) AC
SC301 QSOCN0911REN1 V Socket, 9 Pin(V80T/V91T) AD
SC601 QSOCN0604REN1 V Socket, 6 Pin AB
