Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
VC-V50S
VC-V80T
VC-V91T
74
MECHANISM CHASSIS PARTS
1 LBNDK1011AJZZ V Tension Band Ass’y AH
2 LBOSZ1007AJZZ V Tension Arm boss AD
4 LBOSZ1006AJZZ V Cassette Stay L AD
5 LCHSM0174AJZZ V Main Chassis Ass’y AV
6 LHLDZ2016AJZZ V Loading Motor Block AG
7 LPOLM0070GEZZ J Supply Pole Base Ass’y AK
8 LPOLM0064GEZZ J Take-up Pole Base Ass’y AM
9 MLEVF0518AJZZ V Take-up Loading AF
Arm Ass’y
10 MLEVF0519AJZZ V Supply Loading AF
Arm Ass’y
11 MLEVF0499AJZZ V Pinch Drive Lever Ass’y AG
12 MLEVF0500GEZZ J Pinch Roller Lever Ass’y AW
15 MLEVF0523AJZZ V Tension Arm Ass’y AH
16 LANGF9620AJFW V A/C Head Plate AG
17 MLEVP0271AJZZ V Shifter Drive Lever AE
18 MLEVP0272AJZZ V Pinch Double Action Lever AD
19 MLEVP0301AJZZ V Reverse Guide Lever Ass’y AL
20 MLEVP0275AJZZ V Reverse Drive Lever AD
21 MLEVP0292AJZZ V Slow Brake Lever AE
22 MLEVP0336AJZZ V Open Lever AD
23 MLEVP0293AJZZ V Clutch Lever AE
24 MLEVP0324AJZZ V Supply Main Brake Ass’y AF
25 MLEVP0325AJZZ V Take-up Main Brake AF
Ass’y
27 MSLiP0010AJZZ V Shifter AH
29 MSPRD0175AJFJ V Reverse Guide Spring 2 AE
30 MSPRT0402AJFJ V Loading Double Action AE
Spring
31 MSPRT0403AJFJ V Pinch Double Action AD
Spring
32 MSPRC0213AJFJ V Earth Spring AC
33 MSPRT0416AJFJ V Tension Spring AD
34 NBLTK0067AJ00 V Reel Belt AE
35 NDAiV1078AJ00 V Reel Disk AE
36 NGERH1293AJZZ V Loading Connect Gear AD
37 NGERH1295AJ00 V Master Cam AE
38 NGERH1294AJZZ V Casecon Drive Gear AD
39 NGERH1270AJZZ V Take-up Loading Gear AF
40 NGERH1271AJZZ V Supply Loading Gear AD
41 NGERH1272AJZZ V Pinch Drive Cam AE
43 NGERH1299AJZZ V Reel Relay Gear AE
44 NGERW1070AJZZ V Worm Gear AD
45 NGERW1066AJZZ V Worm Wheel Gear AD
46 NiDR-0018AJZZ V Idler Wheel Ass’y AK
47 NPLYV0162AJZZ V Motor Pully AD
48 NPLYV0163AJZZ V Limiter Pulley Ass’y AM
49 NROLP0131GEZZ J Guide Roller AL
50 NSFTP0032AJZZ V Tension Pole Adjuster AB
51 MSPRC0217AJFJ V Guide Roller Spring AC
52 PREFL1011AJZZ V Light Guide AE
53 QCNW-8022AJZZ V FFC for Drum Motor AD
55 QCNW-8021AJZZ V FFC for A/C Head AD
56 QPWBF5243AJZZ V A/C Head PWB AE
57 QSOCN0696REZZ V Socket, 6 pin AB
58 RHEDT0036AJZZ V Full Erase Head AM
59 RHEDU0088GEZZ J A/C Head Ass’y AV
60 RMOTM1078GEZZ J Loading Motor AP
61 RMOTN2055GEZZ J Capstan D.D. Motor BA
62 RMOTP1139GEZZ J Drum Drive Motor AT
63 DDRMW0028TEX1 V Upper and lower drum BP
Ass’y(V50S)
63 DDRMW0030TEX4 V Upper and lower drum BU
Ass’y(V80T/V91T)
65 QBRSK0041GEZZ J Drum Earth Brush AD
66 XBPSD26P05J00 V Drum Drive Motor AA
Mounting Screw
(SW2.6P+5S)
67 PGiDC0056GEFW J Drum Base AL
68 QPWBF5468AJZZ V PWB(LDG Motor) AE
69 QPLGZ0292GEZZ J Socket(LDG Motor) AE
70 MSPRC0223AJFJ V Azimuth Spring AC
71 MSPRC0224AJFJ V Height Adjusting spring AC
SCREW, NUTS AND WASHERS
201 XBPSD26P08000 V Screw 2.6P+8S A/C Head AA
202 LX-HZ3082GEZZ J WSW2.6+6(AC) AD
203 XHPSD26P06000 V Screw, 2.6P+6S AA
(For Capstan Motor)
207 XHPSD30P08WS0 V Screw, C3.0P+8S AA
(For Drum Base)
208 XRESJ30-06000 V E-Ring, E-3 AA
209 XWHJZ31-03052 V Washer, W3.1-5.2-0.3 AC
210 XWHJZ31-04052 V Washer, W3.1-5.2-0.4 AC
211 XWHJZ31-05052 V Washer, W3.1-5.2-0.5 AC
212 XWHJZ31-06052 V Washer, W3.1-5.2-0.6 AC
213 XWHJZ31-07052 V Washer, W3.1-5.2-0.7 AC
214 PSPAP0009AJZZ V Reverse Guide AB
Adjusting Nut
216 LX-WZ1041GE00 J CW 2.6-6-0.5 CAM AA
218 XBPSD30P08J00 V Drum Base Mounting AA
Screw(SW 3P+8S)
219 LX-WZ1098GE00 J CW 2.6-4.7-0.5 RED AB
220 LX-BZ3096GEFD J Tilt Adjusting Screw AA
221 XBPSD26P06000 V Azimuth Adjusting Screw AA
2.6+6S
222 LX-BZ3197GEFD J Screw(A/C Head) AD
223 XWHJZ31-08052 V Washer, W3.1-5.2-0.8 AC
CASSETTE HOUSING CONTROL PARTS
300 CHLDX3081TEV2 V Cassette Housing AX
Control Ass’y
301 LANGF9592AJFW V Upper Plate AL
302 LHLDX1028AJ00 V Frame (L) AH
303 LHLDX1032AJ00 V Frame (R) AH
304 LHLDX1030AJZZ V Holder (L) AE
305 LHLDX1031AJZZ V Holder (R) AE
306 MLEVF0469AJFW V Proof Lever (R) AE
307 MLEVP0281AJ00 V Door Open Lever AD
308 MSLiF0076AJFW V Slider AK
309 MSPRD0151AJFJ V Proof Lever (R) Spring AB
310 MSPRD0166AJFJ V Drive Gear (R) Spring AE
311 MSPRP0175AJFJ V Cassette Spring AE
312 MSPRT0381AJFJ V Double Action Spring AC
313 NGERH1278AJZZ V Drive Gear L AE
314 NGERH1309AJZZ V Drive Gear R AE
315 NGERR1008AJ00 V Double Action Rack Gear AE
316 NGERR3005AJFW V Drive Angle Gear AG
317 NSFTD0041AJFD V Main Shaft AH
CABINET PARTS
600 GCABA1090AJSB V Top Cabinet AM
601 GCABB1220AJSB V Main Frame AN
602 GCOVA2052AJZZ V Antenna Terminal Cover AG
(V80T/V91T)
602 GCOVA2050AJZZ V Antenna Terminal Cover AH
(V50S)
603 LANGQ9067AJFW V Earth (Pow. Side) AD
604 LANGQ9068AJFW V Earth (Conv. Side) AD
605 XHPSD30P06WS0 V Screw AA
606 PSLDM4519AJFW V Head Amp. Shield AD
607 XEPSD30P14XS0 V Screw AB
608 XEBSD30P12000 V Screw AA
609 XHPSD26P06WS0 V Screw AA
610 LX-HZ3087GEFN J Screw AB
611 PSLDM4566AJFW V Shield Plate AD
613 TLABM4310AJZZ V Model Label(V50S) AC
613 TLABM4312AJZZ V Model Label(V80T) AC
613 TLABM4313AJZZ V Model Label(V91T) AC
614 PSLDM4536AJFW V Shield AK
615 XJPSD30P10WS0 V Screw AA
616 PGUMS0026AJZZ V Foot Felt AB
To Next Page
