Sharp XG-C330X Service Manual

XG-C330X/C430X
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES
N DUNTKD851WEF0 CR N R Main Unit
N DUNTKD868WEF0 BZ N R Terminal Unit
N DUNTKD869WEF0 N R KEY Unit
N DUNTKD870WEF0 BT N R Power Unit
N DUNTKD871WEF0 AW N R INLET Unit
N DUNTKD874WEF0 AN N R RC Unit
N DUNTKD875WEF0 BF N R Condenser Unit
N RDENCA179WJZZ CF N R Ballast Unit
[2] DUNTKD851WEF0 (MAIN Unit)
C1101 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1102 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1103 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1104 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1105 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1106 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1107 VCKYCY1AB105KY AB R Capacitor, 1 10V Ceramic
C1108 VCCCCY1HH102JY AB R Capacitor, 1000p 50V Ceramic
C1109 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1110 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1111 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1112 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1113 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1114 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1115 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1116 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1117 RC-KZA048WJZZY AD R Capacitor, 10 25V Ceramic
C1118 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1119 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1120 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1121 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1122 VCEAPF1EW336MY AD R Capacitor, 33 25V Electrolytic
C1123 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1124 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1125 VCEAPF1EW336MY AD R Capacitor, 33 25V Electrolytic
C1126 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1127 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1129 VCKYCY1HB103KY AA R Capacitor, 0.01 50V Ceramic
C1130 VCKYCY1HB103KY AA R Capacitor, 0.01 50V Ceramic
C1131 RC-KZA117WJZZY AC R Capacitor, 10 6.3V Ceramic
C1132 RC-KZA117WJZZY AC R Capacitor, 10 6.3V Ceramic
C1201 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1202 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1203 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1204 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1205 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1206 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1207 VCKYCY1AB105KY AB R Capacitor, 1 10V Ceramic
C1208 VCCCCY1HH102JY AB R Capacitor, 1000p 50V Ceramic
C1209 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1210 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1211 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1212 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1213 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1214 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1215 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1216 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1217 RC-KZA048WJZZY AD R Capacitor, 10 25V Ceramic
C1218 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1219 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1220 VCKYCY1EF104ZY AA R
Capacitor, 0.1 25V Ceramic
C1221 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1222 VCEAPF1EW336MY AD R Capacitor, 33 25V Electrolytic
C1223 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1224 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1225 VCEAPF1EW336MY AD R Capacitor, 33 25V Electrolytic
C1226 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1227 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1229 VCKYCY1HB103KY AA R Capacitor, 0.01 50V Ceramic
C1230 VCKYCY1HB103KY AA R Capacitor, 0.01 50V Ceramic
C1231 RC-KZA117WJZZY AC R Capacitor, 10 6.3V Ceramic
C1232 RC-KZA117WJZZY AC R Capacitor, 10 6.3V Ceramic
C1301 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1302 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1303 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1304 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1305 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1306 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1307 VCKYCY1AB105KY AB R Capacitor, 1 10V Ceramic
C1308 VCCCCY1HH102JY AB R Capacitor, 1000p 50V Ceramic
C1309 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1310 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1311 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1312 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
C1313 VCKYCY1EF104ZY AA R Capacitor, 0.1 25V Ceramic
