Sharp XG-C330X Service Manual

XG-C330X/C430X
2 – 5
[5] Removing the Power Unit, Inlet Unit, RC Unit and CONDENSER Unit.
1. Remove the 3 screws and Detach the Power Unit.
2. Detach the Inlet Unit.
3. Detach the R/C unit.
4. Remove the 1screw and detach the Condenser Unit.
5-4
5-1
POWER
Unit
Condenser
Unit
Inlet
Unit
5-3
R/C Unit
