References
Specifications
As part of our policy of continuous improvement, SHARP reserves
the right to make design and specification changes for product
improvement without prior notice. The performance specification fig-
ures indicated are nominal values of production units. There may be
some deviations from these values in individual units.
! General
! Amplifier
! Tuner
! CD player
! Cassette deck
! Speaker
Power source AC 230 V, 50 Hz
Power
consumption
Power on: 25 W
Power stand-by: 0.9 W
Dimensions Width: 160 mm
Height: 242 mm
Depth: 250 mm
Weight 2.3 kg
Output power PMPO: 30 W (total)
MPO: 15 W (7.5 W + 7.5 W) (DIN 45 324)
RMS: 10 W (5 W + 5 W) (DIN 45 324)
Output terminals Speakers: 4 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Frequency range FM: 87.5 - 108.0 MHz
AM: 522 - 1,620 kHz
Type Compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency
response
125 - 8,000 Hz (normal tape)
Signal/noise ratio 50 dB (recording/playback)
Wow and flutter 0.35 % (DIN 45 511)
Type 10 cm full-range speaker
Maximum input
power
10 W
Rated input power 5 W
Impedance 4 ohms
Dimensions Width: 130 mm
Height: 240 mm
Depth: 161 mm
Weight 1.4 kg/each
