3 - INSTALLATION AND TRAIAL RUN
42
9) HST neutral position adjustment
① Jack up the front and rear wheels off the ground and
jack stands under the main frame. Make sure all
four wheels are clear of the ground.
② Start the engine and set the low engine speed.
③ Place the range gear change lever to low speed
position.
④ If the wheels rotate at this time, loosen the bolt (A)
until can be rotating the boss (B).
z The boss (B) gradually tern to R direction
until stop the wheels when the wheels rotating
to the forward direction.
z The boss (B) gradually tern to F direction until
stop the wheels when the wheels rotating to
the reverse direction.
⑤ Stop the engine and remove the jack stands, and
lower the tractor on the ground.
⑥ While seated on the operator’s seat, start the engine
and place the low range and increase the engine
speed to full throttle. The tractor should not move
in either direction.
