ENGINE SYSTEMS
49
2. REMOVAL
2
Disassembly
Order Parts Name
1
Muffler・Gasket
2
Exhaust manifold・Gasket
3 Alternator
4 Starting motor
5 Oil filter
6 Relief valve
7 Oil level gauge · Gauge guide
8 Engine stop solenoid · Seal washer
9 Injection pipe
10 Injection pump
NOTE:
1. Remove the injection pipes and engine stop solenoid before remove the injection pump.
2. Raise the injection pump and remove the governor link from the control rack.
3. Injection timing has been adjusted by the shims between injection pump and cylinder block.
Take note of their thickness and number when removing the injection pump.
