ENGINE SYSTEMS
92
Unit Part Inspection Items
Standard
Dimension
Standard Value To be Repaired
Allowable
Limit
Remarks
INJECTION
NOZZLE
Type 093500
3320 DENSO
Injection pressure MPa (kgf/cm
2
)
11.76
(120)
11.27 – 12.25
(115 – 125)
Angle of injection direction
4°
COOLING
SYSTEM
COOLING
Cooling method Water colded, forced circulation
Coolant capacity (ℓ) 3.5
Thermostat open temperature (°C)
82 80 – 84
Thermostat full-open temperature
(°C)
95
V belt M30
ELECTRICAL SYSTEM
STARTER MOTOR
Type 428000 – 2540 DENSO
No. of teeth of pinion gear 9
Shifting method of pinion Magnetic shift type
Wear of commutator diameter 30 29
Stepped wear of commutator 0.05 0.2
Bending allowance of armature shaft 0.05 More than 0.08
Length of brush 13.5 9
Spring force of brush N (kgf) 16.7 (1.7)
Less than
11.76 (1.2)
ALTER MATOR
Type 101211 – 1390 DENSO
Outside diameter of slip ring 14.4 14.0
Length of brush 10.5 4.5
Pulley tightening torque
N⋅m (kgf⋅m)
58.3 – 78.8
(5.95 – 8.05)
To Next Page
