14
(5) Event setting
Types of event must be set before setting event values.
Modifying the event type codes however initializes setting values (data) related to events.
1) Types of event (alarm type) setting
Select event type code from among non, Hd, Ld, od, id, HA, LA, So, run, rot1, StPS, PtnS, EndS, HoLd, ProG, u_SL, d_SL,
or GUA on the “4-1 EV1 type setting screen” of screen group 4 with the Ģ key or ġ key and enter the event type with
the ģ key.
Set event type of EV2 on the “4-7 EV2 type setting screen” in the same manner. The types of event for which event values
can be set are the following 6 types:
Event type (alarm type) code: : higher limit deviation : lower limit deviation
: outside higher/lower limit deviation : inside higher/lower limit deviation
|: higher limit absolute value |: lower limit absolute value
If an event type (alarm type) code other than the above is selected, event values cannot be set.
2) Event values setting
Event values are set on the “0-10 FIX EV1 set values setting screen” and “0-11 FIX EV2 set values setting screen.”
Event values are displayed when one of the previously mentioned 6 types of events is selected.
Event values are set within the following setting range by pressing the Ģ key or ġ key on the 0-10 or 0-11 screen.
When the event value setting has been decided, enter by pressing the ģ key and all SV lamps light.
Setting range: Higher limit deviation or lower limit deviation: -1999–2000 digits
Outside or inside higher/lower limit deviation: 0–2000 digits
Higher limit absolute value or lower limit absolute value: Within measuring range
Event values cannot be set during auto tuning (AT) execution. AT must first be canceled.㻌㻌
0-10 FIX event 1 (EV1 setting)
Ģ
key
ģ
key
Press
Ä
Ä
During modification Enter
All SV lamps flash All SV lamps light
(6) Multi SV (target set values)
1) Multi SV
You can set 2 types of target set values (SV). (SV1, SV2)
SV values are set on the “1-3 FIX control SV1 setting screen” and “1-4 FIX control SV2 setting screen” and execution SV
No. is selected on the “1-2 Execution SV No. selection screen.”
PID No. during multi SV is SV1/PID1 and SV2/PID2.
2) External selection switching of multi SV
If equipped with external control input DI, when SV is allocated to DI, execution SV can be selected from SV1 or SV2 by DI input.
Using 1 point of DI, SV is allocated on the “4-13 DI1 mode setting screen.”
Please refer to the “8-4. External control input (DI).”
Note: Definition of digit
Used as a minimum unit for industrial amounts such as °C and %RH.
If input temperature range is 0.0–200.0, 1 digit = 0.1°C.
If input temperature range is 0–1200, 1 digit = 1°C.
~i
rm
~i
jrh
~i
jrh
