Shimadzu ATY224R User Manual

BEFORE
WEIGHING
MAINTENANCE
TROUBLESHOOTING
FOR YOUR
INFORMATION
USING THE
BALANCE
USING MORE CONVENIENTLY
75
V
Continued on next page
3
Select the value for the stability
detection range.
(stability detection range that you
wish to select)
Select the stability detection range from among
the following options depending on the weighing
application and purpose: 0.5d, 1d, 10d, 50d,
100d, 1000d.
4
Conrm and return to the
weighing mode.
[SET] or
The stability detection range has now been set.
*
If data output is slow…
There are factors in the installation environment and the sample that make the display unstable. If data
output triggered by stability detection is very slow, increase the stability detection range.

Setting the Stability Mark Lighting Timing
The timing according to which (the stability mark) lights can be set in accordance with the
application and required accuracy.
*
Notapplicabletoaveriedbalanceasalegalmeasuringinstrument.
Effect of speeding up
the timing for lighting
up of the stability
mark
At the same time as stability is detected, (the stability mark) lights up.
The weight reading after (the stability mark) lights up becomes more
susceptibletouctuationsincemanysamplescanbeweighedinsuccession
andtheworkingtimecanbeusedmoreefciently(improvementofweighing
speed).
Effect of setting
the stability mark
lighting timing to the
standard setting
Whenstabilityisdetectedandremainsdetectedforaxedtime, (the
stability mark) lights up.
(the stability mark) lighting judgments become stricter and the weight
reading is stable after it has lit, so highly accurate weighing is possible
(improvement of reliability of data).
! ! ! !1!0!D
! !S!E!T! !
! ! ! !1!0!D
Upon setting, the stability mark
lights up.
