NOTICE
• Check that the inner cable is correctly seated inside the pulley guide.
LOCK
Guide
LOCK
LOCK
Guide
7. Secure the cable to the frame with the outer casing bands.
Outer casing bands
10 mm
10 mm
15 mm
