Shimano SW-EN600-L Dealer's Manual

Set the plug of the electric wire to the TL-EW300.
If there is an alignment tab on the plug of the electric wire, check the shape of the E-TUBE port you are
trying to connect to, and set it aligned with the alignment tab.
Without alignment tab on plug
Groove
Guide
Groove
Guide
Alignment tab
With alignment tab on plug
1.
Installation/removal
Electric wires
13
