Shimano SW-EN600-L Dealer's Manual

Removing the electric wire (EW-SD300)
Connecting the electric wire (EW-SD50)
Connect the electric wire to the E-TUBE port.
Remove the electric wire.
* As shown in the figure, use part (A) of the TL-EW300 as a fulcrum, move the tool like a lever, then
disconnect the plug part.
(A)
(1) (2)
Insert the TL-EW300 into the groove on the plug part of the electric wire.(1)
Disconnect the electric wire from the E-TUBE port.(2)
If there is limited space to insert the tool, you can use the TL-EW300 as indicated in the figure to
disconnect the electric wire.
1.
Installation/removal
Electric wires
15
