Shimano SW-EN600-L Dealer's Manual

Set the plug of the electric wire to the TL-EW02.
If there is an alignment tab on the plug of the electric wire, set it aligned with the groove on the SHIMANO
original tool.
Without alignment tab on plug With alignment tab on plug
1.
Insert the plug on the electric wire into the E-TUBE port.
Push it straight in until you feel a click.
E-TUBE port
Plug
2.
Installation/removal
Electric wires
16
