Shini SCD Series User Manual

122(202)
Table 2-39：Electrical Components List (PLC)(SCD-900U/700H)
SCD-900U/700H
No. Symbol Name
Specification Part No.
1 Q1 Main switch* 80A YE40601500000
2 Q2 Excitation break away 60A YE40606000000
3 K1 Contactor** 230VAC 50Hz YE00422200100
4 K2 Contactor** 230VAC 50Hz YE00401000100
5 K3 Contactor** 230VAC 50Hz YE00401000100
6 K4 Contactor** 230VAC 50Hz YE00462200100
7 K5 Contactor** 230VAC 50Hz YE00431100000
8 K6 Phase protector 230VAC 50Hz YE03103800000
9 K8 Relay 230VAC 50Hz 12A YE03270700000
10 A1 PLC 100-230VAC 50/60Hz YE81022400100
11 A2 Analog module - YE82023100100
12 A4 Human-machine interface 24VDC 0.4A YE80601000000
13 A3 Analog module - YE82023100000
14 S13 Dew-point transducer POWER=24VDC OUT=4~20mA YE15041200000
15 F1 Overload relay 10-16A YE01101600100
16 F2 Overload relay 2.5-4A YE01025400000
17 F3 Overload relay 4-6.3A YE01046300100
18 F4 Fuse* 2A Fuse YE41001000000
19 S1 Level switch** 20-24VDC YE15123200000
20 S2 S3 Photoelectric switch** 10-30VDC YE15143900000
21 S4 Limit switch** 250V~5(4)A YE14511100000
22 S5 S6 Overheat protector* 250V~5(4)A YE21503000000
23
S10 S11
S12
Thermocouple** K BE90802000050
24
Y1 Y2 Y3
Y4 Y5
Magnetic valve** 230VAC 50/60Hz YE32051800300
25 U DC power OUT=DC24V 1.5A YE71352400000
26 H1 Buzzer 60-250V AC/DC 5~35mA YE84003500200
27 H2 Alarm indicate lamp 230VAC 50Hz YE83305100300
28 T Transformer** IN=400V OUT=230V 500mA YE70402300800
29 X1 Terminal board 76A 690V -
30 - - - -
31 - - 57A 690V -
32 - - - -
33 - - 41A 690V -
34 - - - -
35 X2 Terminal board 32A 690V -
36 X3 Terminal board 10A 250V -
