Shini SCD Series User Manual

133(202)
2.7.14 Electrical Components List (PCB) (230V)
Table 2-43：Electrical Components List (PCB)(SCD-20U/40U-30H) (230V)
No. Symbol Name Specifications Part No.
1 Q1 Main switch* 32A YE10220300000
2 Q2 Circuit-breaker 20A
YE40602000100
YE40000900000
3 Q3 Circuit-breaker * 15A YE40601500000
4 K1 Contactor** 230VAC 50Hz YE00301000000
5 K2 Contactor** 230VAC 50Hz YE00301000000
6 K3 Contactor** 230VAC 50Hz YE00300000000
7 K4 Contactor** 230VAC 50Hz YE00300000000
8 K5 Contactor** 230VAC 50Hz YE00300000000
9 K6 K11 Relay 230VAC 50Hz 5A YE03270700000
10 K7 Timer 230VAC 3S-60M YE86300300000
11 K9 Temperature controller* 230VAC 50Hz YE85050400000
12 PCB-01 PCB** STC43/44 YE80001500000
13 PCB-02 PCB** 18VAC YE80101100000
14 PCB-03 PCB - YE80010200000
15 K8
Dew-point meter
230VAC 50/60Hz YE85122000100
16 S3
Dew-point transducer
POWER=24VDC OUT=4~20mA YE15041200000
17 F1
Overload relay
1.6~2.5A YE01162500000
18 F2
Overload relay
1.6~2.5A YE01162500000
19 F3
Overload relay
3.2~5A YE01032500000
20 F4 Fuse** 0.5A
YE41001000000
YE46630500000
21 F5 F6
Fuse**
2A YE41001000000
22 S1
Level switch**
20-24VDC YE15123200000
23 S2
Photoelectric switch**
10-30VDC YE15143900000
24 S4
Limit switch*
250V 5(4)A YE14511100000
25 S5 S9
Overheat protector*
250V 5(4)A YE21503000400
26 S6
Overheat protector
250V 5(4)A YE21503000400
27 S7 S8
Thermocouple**
K BE90802000050
28 Y1 Y2
Magnetic valve**
230VAC 50/60Hz YE32051800300
29 H1
Buzzer
24VDC YE84002700000
30 H2
Alarm indicate lamp
230VAC 50Hz YE83305100300
31 Z
EMI
250VAC 1A YE73011100000
32 T
Transformer**
IN=230V/200V OUT=20V 350mA YE70202300400
33 X1
Terminal board
57A 690V YE61060000000
34 -
-
- YE61063500000
35 -
-
32A 690V YE61250000000
