86(202)
2.7.9 Electrical Components List (PLC)
Table 2-21：Electrical Components List (PLC)(SCD-20U/30H)
SCD-20U/30H
No. Symbol
Name
Specification Part No.
1 Q1 Main switch* 16A YE10200300000
2 Q2 Excitation break away 15A S9 YE40601600000
3 Q3 Circuit breakers* 15A YE40000900000
4 K1 Contactors** 230VAC 50Hz YE40600300000
5 K2 Contactors** 230VAC 50Hz YE40600300000
6 K3 Contactors** 230VAC 50Hz YE40600300000
7 K4 Contactors** 230VAC 50Hz YE00311000000
8 K5 Contactors** 230VAC 50Hz YE00311000000
9 K6 Phase protector 230VAC 50Hz YE03103800000
10 K7 Relay 230VAC 50Hz 12A YE03270700000
11 A1 PLC 100-230VAC 50/60Hz YE81022400100
12 A2 Analog module - YE82023100100
13 A4 Human-machine interface
24VDC 0.4A YE80211000000
14 A3 Analog module - YE82023100100
15 S13 Dew-point transducer POWER=24VDC OUT=4~20mA YE15041200000
16 U DC power OUT=DC24V 1.5A YE71352400000
17 F1 Overload relay 1-1.6A YE01011600000
18 F2 Overload relay 9-13A YE01091300100
19 F3 Overload relay 2-3.2A YE01023200000
20 F4 Fuse* 2A Fuse YE41001000000
21 S1 Level switch ** 20-24VDC YE15123200000
22 S2 S3 Photoelectric switch ** 10-30VDC YE15143900000
23 S4 Limit switch * 250V~5(4)A YE14511100000
24 S5 Overheat protector * 250V~5(4)A YE21503000400
25 S6 Overheat protector * 250V~5(4)A YE21503000400
26 S7 S8 S9
Thermocouple ** K BE90250000050
27
Y1 Y2 Y3
Y4 Y5
Magnetic valve ** 230VAC 50/60Hz YE32051800300
28 H1 Buzzer 60-250V AC/DC 5~35mA YE84003500200
29 H2 Alarm indicate lamp 230VAC 50Hz YE83305100200
30 Z1 Z2 RC Suppressor 110-250VAC M-04
31 T Transformer ** IN=400V OUT=230V 500mA YE70402300800
32 X1 Terminal board 41A 690V YE61040000000
33 - - - YE61043500000
34 - - 32A 690V YE61250000000
35 - - - YE61253500000
To Next Page
