176(202)

3.4 Installation of Blowers

3.4.1 Drying Blower

1) Fix inlet/outlet flange of blower, and tighten 4 screws securely.

2) Connect the blower with electrical source.

3) Install the blower on the Machine frame.

Picture 3-7：Installation of Blowers

3.4.2 Regeneration Blower

1) Fix inlet/outlet flange of blower, and tighten 4 screws securely.

2) Install the blower on the machine frame.

3) Connect the blower with electrical source.

3.4.3 Conveying Blower

1) Fix inlet/outlet flange of blower, and tighten 4 screws securely.

2) Connect the blower with electrical power source.

3) Install the blower on the machine frame.

4) Fix the three-way valve (See Figure. 1).

5) Install the solenoid valve, and then tighten 2 screws on the machine frame

(See Figure. 2).

Picture 3-8：Conveying Blower

3.4.4 Installation of Drying Hopper
