Shini SCD Series User Manual

30(202)
2.6.3 Parts List (Fully-integral design)
Table 2-1：Parts List (Fully-integral design)(SCD-20U/30H~40U/50H)
Part No.
No. Description
20U/30H 40U/30H 40U/50H
1 Sight-glass window - - -
2 Sight-glass window retainer - - -
3 Hopper fixing plate - - -
4 Hopper top cover - - -
5 Insulated hopper - - -
6 Shut-off valve BY10203800050 BY10203800050 BY10203800050
7 Locking pin assembly - - -
8 Front door frame - - -
9 Front door plate - - -
10 Front door key YW00717100000 YW00717100000 YW00717100000
11 Front door plate (left) - - -
YW03000300200 YW03000300200 YW03000300200
12 Castor
YW03000300000 YW03000300000 YW03000300000
13 Front plate (left) - - -
14 Control box door - - -
15 Touch screen YE80211000000 YE80211000000 YE80211000000
16 Main switch* YE10200300000 YE10200300000 YE10200300000
17 Exhaust fan** YM60121200400 YM60121200400 YM60121200400
18 Control box - - -
19 Process heater* BH70400300050 BH70400300050 BH70803900050
20 Honeycomb YW71152000100 YW71152000100 YW71182000100
21 Double-head screw BH10533000010 BH10533000010 BH10533000010
22 Honeycomb upper cover YA40003000100 YA40003000100 BA40508000130
23 Honeycomb bottom cover YA40003000000 YA40003000000 BA40508000030
24 Right side plate - - -
25 Heat-resistant tube** YW72023600000 YW72023600000 YW72023600000
26 Flange - - -
27 Top plate - - -
28
Honeycomb mounting
bracket
- - -
29 Regen. heater* BH70300300050 BH70300300050 BH70500300050
30 Cooler BW88030500020 BW88030500020 BW88030500020
31 Regen. blower* BM30012500050 BM30012500050 BM30012500050
32 Process blower* BM30012500050 BM30012500050 BM30020500050
33 Middle separating plate - - -
34 Inner side plate - - -
