Shini SCD Series User Manual

56(202)
2.7.5 Electrical Components List (PCB) (400V)
Table 2-9：Electrical Components List (PCB)(SCD-20U/40U-30H) (400V)
No. Symbol Name Specifications Part No.
1 Q1 Main switch* 16A YE10200300000
2 Q2 Circuit-breaker 16A YE40601600000
3 Excitation break away 220VAC-240VAC YE40000900000
4 Q3 Circuit-breaker* 10A YE40600300000
5 K1 Contactor** 230VAC 50Hz YE00402200100
6 K2 Contactor** 230VAC 50Hz YE00301000000
7 K3 Contactor** 230VAC 50Hz YE00300000000
8 K4 Contactor** 230VAC 50Hz YE00300000000
9 K5 Contactor** 230VAC 50Hz YE00300000000
10 K6 Relay 230VAC 50Hz 5A YE03270700000
11 K8 Dew-point meter 230VAC 50/60Hz YE85122000100
12 K9 Temperature controller* 230VAC 50Hz YE85050400000
13 PCB-01 PCB** STC43/44 YE80001500000
14 PCB-02 PCB** 18VAC YE80101100000
15 PCB-03 PCB - YE80010200000
16 F1 Overload relay 1~1.6A YE01011600000
17 F2 Overload relay 1~1.6A YE01011600000
18 F3 Overload relay 2~3.2A YE01023200000
19 F4 Fuse** 2A Fuse YE41001000000
20 F5 Fuse** 1A Fuse
YE41001000000
YE46630100000
21 S1 Level switch** 20-24VDC YE15123200000
22 S2 Photoelectric switch** 10-30VDC YE15143900000
23 S3 Dew-point transducer POWER=24VDC OUT=4~20mA YE15041200000
24 S4 Limit switch* 250V 5(4)A YE14152400000
25 S5 Overheat protector* 250V 5(4)A YE21503000400
26 S6 Overheat protector 250V 5(4)A YE21503000400
27 S7 S8 Thermocouple** K BE90802000050
28 Y1 Y2 Magnetic valve** 230VAC 50/60Hz YE32051800300
29 H1 Buzzer 24VDC YE84002700000
30 H2 Alarm indicate lamp 230VAC 50Hz YE83305100300
31 T Transformer** IN=400V OUT=230V/20V 500mA YE70504000000
32 X1 Terminal board 32A 690V YE61250000000
33 - - - YE61253500000
34 X2 Terminal 10A 250V YE60001500000
35 - - 10A 250V YE60001000200
36 - - 10A 250V YE60001000000
