Shini SCD Series User Manual

15(202)
Table 1-2：Specifications (Semi-integral Design)
Model SCD- 450U/300H 600U/300H 600U/400H 750U/400H 750U/500H 900U/500H 900U/700H 1200U/700H
Drying System
Process Heater
Power (kW)
15 15 18 18 21 21 24 24
Process Blower Power
(kW, 50/60Hz)
2.4 / 3 2.4 / 3 3.75 / 4.5 3.75 / 4.5 5.5* / 6.3* 5.5* / 6.3* 5.5 / 6.3* 5.5 / 6.3*
Drying Hopper
Capacity (L)
450 600 600 750 750 900 900 1200
Dehumidifying System
Regenerating Heater
Power (kW)
7.2 7.2 7.2 7.2 10 10 10 10
Regenerating Blower
Power (kW, 50/60Hz)
0.75 / 0.9 0.75 / 0.9 0.75 / 0.9 0.75 / 0.9 1.5 / 1.8 1.5 / 1.8 1.5 / 1.8 1.5 / 1.8
Dry Air Capacity (m
3
/hr,
50/60Hz)
300 / 400 300 / 400 400 / 450 400 / 450 500 / 570 500 / 570 700 / 780 700 / 780
Conveying System
Conveying Blower
Power (kW, 50/60Hz)
1.5 / 1.8 1.5 / 1.8 1.5 / 1.8 1.5 / 1.8 1.5 / 1.8 2.4 / 2.9 2.4 / 2.9 2.4 / 2.9
Dia. of Conveying
Hose (inch)
1.5 1.5 1.5 1.5 1.5 2 2 2
SHR-U-E Hopper
Receiver (L)
12 12 12 12 12 24 24 24
SHR-U Hopper
Receiver (L)
12 12 12 12 12 24 24 24
Dimensions
H(mm)
2480 2380 2380 2610 2760 2640 2640 3070
W(mm)
1490 1745 1745 1745 2140 2140 2140 2140
D(mm)
1255 1255 1255 1255 1380 1380 1380 1380
Weight (kg)
600 635 640 690 710 820 850 900
Note: 1) For models that are equipped with dew-point monitor, We reserve the right to change
add "D" at model behind. specifications without prior notice.
2) For models with the polished hopper inside, add "P"
at model behind.
3) For models of providing material for two IMMs with
three-stage conveying function and adopt PLC
control plus LCD touch screen, add "LC" at model
behind.
4) Power: 3Φ, 230/400/460/575VAC, 50/60Hz.
