155(202)
Table 2-54：Electrical Components List (PCB)(SCD-900U/1200U-700H) (230V)
No. Symbol
Name Specifications Part No.
1 Q1 Circuit-breaker* 160A YE40633200000
2 Q2 Circuit-breaker 125A YE41161200000
3 - Excitation break away 220VAC-240VAC YE40101600000
4 K1 Contactor** 230VAC 50Hz YE00321100000
5 K2 Contactor** 230VAC 50Hz YE00301000000
6 K3 Contactor** 230VAC 50Hz YE00310000000
7 K4 Contactor** 230VAC 50Hz YE00462200100
8 K5 Contactor** 230VAC 50Hz YE00340000000
9 K6 K11 Relay 230VAC 50Hz 5A YE03270700000
10 K7 Timer 230VAC 3S-60M YE86300300000
11 K9 Temperature controller* 230VAC 50Hz YE85050400000
12 PCB-01 PCB** STC43/44 YE80001500000
13 PCB-02 PCB** 18VAC YE80101100000
14 PCB-03 PCB - YE80010200000
15 K8 Dew-point meter 230VAC 50/60Hz YE85122000100
16 S3 Dew-point transducer POWER=24VDC OUT=4~20mA YE15041200000
17 F1 Overload relay 16~25A YE01162500100
18 F2 Overload relay 5~8A YE01050800000
19 F3 Overload relay 8~12.5A YE01812500000
20 F4 Fuse** 0.5A
YE41001000000
YE46630500000
21 F5 F6 Fuse** 2A YE41001000000
22 S1 Level switch** 20-24VDC YE15123200000
23 S2 Photoelectric switch** 10-30VDC YE15143900000
24 S4 Limit switch* 250V 5(4)A YE14511100000
25 S5 S9 Overheat protector* 250V 5(4)A YE21503000400
26 S6 Overheat protector 250V 5(4)A YE21503000400
27 S7 S8 Thermocouple** K BE90802000050
28 Y1 Y2 Magnetic valve** 230VAC 50/60Hz YE32051800300
29 H1 Buzzer 24VDC YE84002700000
30 H2 Alarm indicate lamp 230VAC 50Hz YE83305100300
31 Z EMI 250VAC 1A YE73011100000
32 T Transformer** IN=230V/200V OUT=20V 350mA
YE70202300400
33 X1 Terminal board - YE61353500000
34 - - - YE61160000000
35 - - - YE61163500000
36 - - 57A 690V YE61060000000
37 - - - YE61063500000
To Next Page
