Table 2-2：Parts List (Fully-integral design)(SCD-80U/50H~160U/120H)
Part No.
No. Description
80U/50H 120U/80H 160U/120H
1 Sight-glass window - - -
2 Sight-glass window retainer - - -
3 Hopper fixing plate - - -
4 Hopper top cover - - -
5 Insulated hopper - - -
6 Shut-off valve BY10163800250 BY10163800250 BY10163800250
7 Locking pin assembly - - -
8 Front door frame - - -
9 Front door plate - - -
10 Front door key YW00717100000 YW00717100000 YW00717100000
11 Front door plate (left) - - -
YW03000300200 YW03000300200 YW03000300200
12 Castor
YW03000300000 YW03000300000 YW03000300000
13 Front plate (left) - - -
14 Control box door - - -
15 Touch screen YE80211000000 YE80211000000 YE80211000000
16 Main switch* YE10200300000 YE10200300000 YE10200300000
17 Exhaust fan** YM60121200400 YM60121200400 YM60121200400
18 Control box - - -
19 Process heater* BH70803900050 BH70160600150 BH70160600150
20 Honeycomb YW71182000100 YW71183000100 YW71184000100
21 Double-head screw BH10533000040 BH10543000040 BH10554500040
22 Honeycomb upper cover BA40508000130 BA40508000130 BA40508000130
23 Honeycomb bottom cover BA40508000030 BA40508000030 BA40508000130
24 Right side plate - - -
25 Heat-resistant tube** YW72023600000 YW72023600000 YW72023600000
26 Flange - - -
27 Top plate - - -
28
Honeycomb mounting
bracket
- - -
29 Regen. heater* BH70500300050 BH70800300050 BH70800300050
30 Cooler BW88030500020 BW88030500020 BW88030500020
31 Regen. blower* BM30012500050 BM30012500050 BM30012500050
32 Process blower* BM30020500050 BM30031000150 BM30031000150
33 Middle separating plate - - -
34 Inner side plate - - -
35 Conveying blower* BM30031000150 BM30031000150 BM30031000150
