34(202)
Table 2-3：Parts List (Fully-integral design) (SCD-230U/120H~300U/150H)
Part No.
No. Description
230U/120H 230U/150H 300U/150H
1 Sight-glass window - - -
2
Sight-glass window
retainer
- - -
3 Hopper fixing plate - - -
4 Hopper top cover - - -
5 Insulated hopper - - -
6 Shut-off valve - - -
7 Locking pin assembly - - -
8 Front door frame - - -
9 Front door plate - - -
10 Front door key YW00717100000 YW00717100000 YW00717100000
11 Front door plate (left) - - -
YW03000300200 YW03000300200 YW03000300200
12 Castor
YW03000300000 YW03000300000 YW03000300000
13 Front plate (left) - - -
14 Control box door - - -
15 Touch screen YE80211000000 YE80211000000 YE80211000000
16 Main switch* YE10220300000 YE10220300000 YE10220300000
17 Exhaust fan** YM60121200400 YM60121200400 YM60121200400
18 Control box BH36023000350 BH36231500150 BH36301500150
19 Process heater* BH70160600150 BH70451200050 BH70451200050
20 Honeycomb YW71184000100 YW71184000100 YW71184000100
21 Double-head screw BH10554500010 BH10543000010 BH10543000010
22 Honeycomb upper cover BA40508000130 BA40508000130 YA40152000100
23 Honeycomb bottom cover BA40508000030 BA40508000130 YA40152000000
24 Right side plate - - -
25 Heat-resistant tube** YW72253600000 YW72253600000 YW72253600000
26 Flange - - -
27 Top plate - - -
28
Honeycomb mounting
bracket
- - -
29 Regen. heater* BH70800300050 BH70150400050 BH70150400050
30 Cooler BW88081200020 BW88081200020 BW88152000020
31 Regen. blower* BM30012500050 BM30020500050 BM30020500050
32 Process blower* BM30031000150 BM30042000050 BM30042000050
33 Middle separating plate - - -
34 Inner side plate - - -
35 Conveying blower* BM30042000050 BM30042000050 BM30042000050
To Next Page
