Shini SCD Series User Manual

41(202)
Table 2-6：Parts List (Semi-integral Design) (SCD-750U/500H~1200U/700H)
Part No.
No. Description
750U/500H 900U/500H 900U/700H 1200U/700H
1 Castor YW03000400200 YW03000400200 YW03000400200 YW03000400200
2
Base frame welding
ring
- - - -
3 Castor brake YW03000400000 YW03000400000 YW03000400000 YW03000400000
4 Front pole - - - -
5 Right lower side plate - - - -
6 Rear pole - - - -
7 Upper side plate - - - -
8 Side fixing beam - - - -
9 Rear bottom plate - - - -
10 Rear top plate - - - -
11 Cover board - - - -
12 Moisture outlet flange - - - -
13 Air outlet flange - - - -
14 Transmission belt** YR00205800000 YR00205800000 YR00205800000 YR00205800000
15 M16 Screw - - - -
16 Washer - - - -
17 Spring YW01180300000 YW01180300000 YW01180300000 YW01180300000
18
Honeycomb upper
cover
BA40304000110 BA40304000110 BA40304000110 BA40304000110
19 Honeycomb YW71443000100 YW71443000100 YW71444000100 YW71444000000
20 Rear fixing beam - - - -
21 Two-head screw BH10554500010 BH10554500010 BH10554500010 BH10554500010
22 Microswitch* YE14152400000 YE14152400000 YE14152400000 YE14152400000
23
Honeycomb bottom
cover
BA40507000010 BA40507000010 BA40507000010 BA40507000010
24 Water distributor - - - -
25 Rear middle beam - - - -
26 Gear motor YM50512600000 YM50512600000 YM50512600000 YM50512600000
27 Side middle beam - - - -
28 Rear middle beam - - - -
29 Front middle beam - - - -
30 Belt regulator pad BH10005000040 BH10005000040 BH10005000040 BH10005000040
31 Terminal block YE61250000000 YE61250000000 YE61250000000 YE61250000000
32 Capacitor YE25001500000 YE25001500000 YE25001500000 YE25001500000
33 Motor* BM30042000050 BM30042000050 BM30042000050 BM30042000050
34 Blower* YM30072900000 YM30072900000 YM30072900000 YM30072900000
35 Cooler YR30010400000 YR30010400000 YR30010400000 YR30010400000
