60(202)
Table 2-11：Electrical Components List (PCB)(SCD-120U/160U-80H) (400V)
No. Symbol
Name Specifications Part No.
1 Q1 Main switch* 25A YE10210300000
2 Q2 Circuit-breaker 20A YE40602000100
3 Excitation break away 220VAC-240VAC YE40000900000
4 Q3 Circuit-breaker* 15A YE40601500000
5 K1 Contactor** 230VAC 50Hz YE00301000000
6 K2 Contactor** 230VAC 50Hz YE00301000000
7 K3 Contactor** 230VAC 50Hz YE00300000000
8 K4 Contactor** 230VAC 50Hz YE00310000000
9 K5 Contactor** 230VAC 50Hz YE00300000000
10 K6 Relay 230VAC 50Hz 5A YE03270700000
11 K9 Temperature controller* 230VAC 50Hz YE85050400000
12 PCB-01 PCB** STC43/44 YE80001500000
13 PCB-02 PCB** 18VAC YE80101100000
14 PCB-03 PCB - YE80010200000
15 K8 Dew-point meter 230VAC 50/60Hz YE85122000100
16 S3 Dew-point transducer POWER=24VDC OUT=4~20mA YE15041200000
17 F1 F3 Overload relay 2~3.2A YE01023200000
18 F2 Overload relay 1~1.6A YE01011600000
19 F4 Fuse** 2A Fuse YE41001000000
20 F5 Fuse** 1A Fuse
YE41001000000
YE46630100000
21 S1 Level switch** 20-24VDC YE15123200000
22 S2 Photoelectric switch** 10-30VDC YE15143900000
23 S4 Limit switch* 250V 5(4)A YE14152400000
24 S5 Overheat protector* 250V 5(4)A YE21503000400
25 S6 Overheat protector 250V 5(4)A YE21503000400
26 S7 S8 Thermocouple** K BE90802000050
27 Y1 Y2 Magnetic valve** 230VAC 50/60Hz YE32051800300
28 H1 Buzzer 24VDC YE84002700000
29 H2 Alarm indicate lamp 230VAC 50Hz YE83305100300
30 T Transformer** IN=400V OUT=230V/20V 500mA
YE70504000000
31 X1 Terminal board 41A 690V YE61040000000
32 - - - YE61043500000
33 - - 32A 690V YE61250000000
34 - - - YE61253500000
35 X2 Terminal 10A 250V YE60001500000
36 - - 10A 250V YE60001000200
37 - - 10A 250V YE60001000000
To Next Page
