Shini SCD Series User Manual

66(202)
Table 2-14：Electrical Components List (PCB)(SCD-230U/300U-150H) (400V)
No. Symbol Name Specifications Part No.
1 Q1 Main switch* 40A YE41104000000
2 Q2 Circuit-breaker 25A YE40632500000
3 Excitation break away 220VAC-240VAC YE40000900000
4 K1 K2 Contactor** 230VAC 50Hz YE00301000000
5 K3 Contactor** 230VAC 50Hz YE00301000000
6 K4 Contactor** 230VAC 50Hz YE00300000000
7 K5 Contactor** 230VAC 50Hz YE00310000000
8 K6 Contactor** 230VAC 50Hz 5A YE03270700000
9 K9 Timer 230VAC 50Hz YE85050400000
10 PCB-01 Temperature controller* STC43/44 YE80001500000
11 PCB-02 PCB** 18VAC YE80101100000
12 PCB-03 PCB** - YE80010200000
13 K8 PCB 230VAC 50/60Hz YE85122000100
14 S3 Dew-point meter POWER=24VDC OUT=4~20mA YE15041200000
15 F1 Dew-point transducer 3.2~5A YE01032500000
16 F2 Overload relay 1~1.6A YE01011600000
17 F3 Overload relay 3.2~5A YE01032500000
18 F4 Fuse** 2A Fuse YE41001000000
19 F5 Fuse** 1A Fuse
YE41001000000
YE46630100000
20 S1 Level switch** 20-24VDC YE15123200000
21 S2 Photoelectric switch** 10-30VDC YE15143900000
22 S4 Limit switch* 250V 5(4)A YE14511100000
23 S5 Overheat protector* 250V 5(4)A YE21503000400
24 S6 Overheat protector 250V 5(4)A YE21503000400
25 S7 S8 Thermocouple** K BE90802000050
26 Y1 Y2 Magnetic valve** 230VAC 50/60Hz YE32051800300
27 H1 Buzzer 24VDC YE84002700000
28 H2 Alarm indicate lamp 230VAC 50Hz YE83305100300
29 T Transformer** IN=400V OUT=230V/20V 500mA YE70504000000
30 X1 Terminal board - YE61063500000
31 - - 32A 690V YE61250000000
32 - - - YE61253500000
33 X2 Contactor** 10A 250V YE60001500000
34 - - 10A 250V YE60001000200
35 - - 10A 250V YE60001000000
36 X3 Terminal 32A 690V YE61250000000
37 - - - YE61253500000
