68(202)
Table 2-15：Electrical Components List (PCB)(SCD-300U/450U-200H) (400V)
No. Symbol
Name Specifications Part No.
1 Q1 Circuit-breaker 50A YE40635000000
2 Q2 Excitation break away 32A
YE40633200000
YE40000900000
3 K1 K2 Contactor** 230VAC 50Hz YE00301000000
4 K3 Contactor** 230VAC 50Hz YE00300000000
5 K4 Contactor** 230VAC 50Hz YE00330000000
6 K5 Contactor** 230VAC 50Hz YE00310000000
7 K6 Contactor** 230VAC 50Hz 5A YE03270700000
8 K9 Timer 230VAC 50Hz YE85050400000
9 PCB-01 Temperature controller* STC43/44 YE80001500000
10 PCB-02 PCB** 18VAC YE80101100000
11 PCB-03 PCB** - YE80010200000
12 K8 PCB 230VAC 50/60Hz YE85122000100
13 S3 Dew-point meter POWER=24VDC OUT=4~20mA YE15041200000
14 F1 Dew-point transducer 3.2~5A YE01032500000
15 F2 Overload relay 1~1.6A YE01011600000
16 F3 Overload relay 3.2~5A YE01032500000
17 F4 Fuse** 2A Fuse YE41001000000
18 F5 Fuse** 1A Fuse
YE41001000000
YE46630100000
19 S1 Level switch** 20-24VDC YE15123200000
20 S2 Photoelectric switch** 10-30VDC YE15143900000
21 S4 Limit switch* 250V 5(4)A YE14511100000
22 S5 Overheat protector* 250V 5(4)A YE21503000400
23 S6 Overheat protector 250V 5(4)A YE21503000400
24 S7 S8 Thermocouple** K BE90802000050
25 Y1 Y2 Magnetic valve** 230VAC 50/60Hz YE32051800300
26 H1 Buzzer 24VDC YE84002700000
27 H2 Alarm indicate lamp 230VAC 50Hz YE83305100300
28 T Transformer** IN=400V OUT=230V/20V 500mA
YE70504000000
29 X1 Terminal board - YE61103500000
30 - - 32A 690V YE61250000000
31 - - - YE61253500000
32 X2 Terminal board 10A 250V YE60001500000
33 - - 10A 250V YE60001000200
34 - - 10A 250V YE60001000000
35 X3 Terminal board 32A 690V YE61250000000
36 - - - YE61253500000
37 X4 X5 Heavy duty connector 4P 10A YE68041000100
To Next Page
