Shinko ACD-13A User Manual

- 21 -
6. Setup
Factory default of this controller:
Input type: K, -200 to 1370
Control action: PID control (with AT), Reverse action (Heating action)
Event output (EVT1, EVT2): No event
Setup (setting the Input type, control action, Event output type, etc.) should be done
before using this controller, according to the user’s conditions.
Setup is conducted in the Engineering group.
The Engineering group consists of Input group, Output group, Event input group (optional),
Event output group, Program group, Communication group, External setting group,
Transmission output group and Other function group.
If the user’s specification is the same as the factory default of the instrument, it is not
necessary to set up the controller. Proceed to Section “7. Settings” (pp. 52-68).
Factory default of the Engineering group
• Input group (pp. 26-28)
Setting Item
Factory Default
Input type
K, -200 to 1370
Scaling high limit
1370
Scaling low limit
-200
Decimal point place
No decimal point
PV filter time constant
0.0 seconds
Sensor correction
0.0
• Output group (pp. 29-31)
Setting Item
Factory Default
OUT1 proportional cycle
Relay contact output: 30 seconds
Non-contact voltage output: 3 seconds
Direct current output: Not available
OUT2 proportional cycle (D option)
Relay contact output: 30 seconds
Non-contact voltage output: 3 seconds
Direct current output: Not available
OUT1 high limit
100%
OUT1 low limit
0%
OUT1 ON/OFF hysteresis
1.0
OUT2 cooling method (D option)
Air cooling
OUT2 high limit (D option)
100%
OUT2 low limit (D option)
0%
Overlap/Dead band (D option)
0.0
OUT2 ON/OFF hysteresis (D option)
1.0
Direct/Reverse action
Reverse action
OUT1 MV preset output
0.0%
OUT2 MV preset output (D option)
0.0%
