- 8 -
1.2 How to Read the Model Label
The model label is attached to the left side of the case.
ACD-13A
Model,
Power supply voltage (“1” is entered for 24 V AC/DC), option
Serial number
(e.g.) Relay contact output / Multi-range input
(Fig. 1.2-1)
ACR-13A
Model,
Power supply voltage (“1” is entered for 24 V AC/DC), option
Serial number
(e.g.) Relay contact output / Multi-range input
(Fig.1.2-2)
