12. Specifications
12.1 Standard Specifications
Rating
Input
Thermocouple
K, J, R, S, B, E, T, N, PL- , C(W/Re5-26):
External resistance, 100 or less
(However, B input: External resistance, 40
max.)
RTD
Pt100, JPt100, 3-wire type
Allowable input lead wire resistance: 10 max.
per wire
Direct current
0 to 20 mA DC, 4 to 20 mA DC:
Input impedance: 50
Allowable input current: 50 mA max.
DC voltage
0 to10 mV DC, -10 to 10 mV DC, 0 to 50 mV
DC, 0 to 100 mV DC, 0 to 1 V DC:
Input impedance: 1 M minimum
Allowable input voltage: 5 V DC max.
Allowable signal source resistance:
0 to 10 mV DC: 20
max.
-10 to 10 mV DC: 40
max.
0 to 50 mV DC: 200 max.
0 to 100 mV DC: 200 max.
0 to 1 V DC: 2 k max.
0 to 5 V DC, 1 to 5 V DC, 0 to 10 V DC:
Input impedance: 100 k minimum
Allowable input voltage: 15 V DC max.
Allowable signal source resistance: 100 max.
Power supply
voltage
100 to 240 V AC 50/60 Hz, or 24 V AC/DC 50/60 Hz
Allowable voltage fluctuation: 100 to 240 V AC: 85 to 264 V AC
24 V AC/DC: 20 to 28 V AC/DC
General structure
External
dimensions
ACD-13A: 96 x 96 x 100 mm (W x H x D)
ACR-13A: 48 x 96 x 100 mm (W x H x D)
Mounting
Flush
Material
Case: Flame-resistant resin
Color
Case: Black
Drip-proof/
Dust-proof
IP66 (for front panel only)
Display
PV Display
11-segment LCD 5-digit,
Backlight Red/Green/Orange
Character size:
ACD-13A: 24.0 x 11.0 mm (H x W)
ACR-13A: 14.0 x 5.4 mm (H x W)
