Shinko ACD-13A User Manual

- 7 -
1. Model
1.1 Model
ACD-1 3 A -
/ M ,
ACR-1 3 A - / M ,
ACD-13A (W96 x H96 x D100 mm)
ACR-13A (W48 x H96 x D100 mm)
Control
action
3 PID
Event output
EVT1, EVT2
A Selectable by front keypad (*1)
Control output
(OUT1)
R
Relay contact: 1a1b
S
Non-contact voltage (for SSR drive):
12 V DC 15%
A
Direct current: 4 to 20 mA DC
Input
M
Multi-range (*2)
Power supply voltage
100 to 240 V AC (standard)
1
24 V AC/DC (*3)
Options
(Multiple options selectable)
EI
Event input
A3
Event output (EVT1 to EVT3)
A5
Event output (EVT4, EVT5)
W
Single-phase
Heater burnout
alarm (*4)
W3
3-phase
DR
Relay contact: 1a
Heating/Cooling
control output
(OUT2)
DS
Non-contact voltage
(for SSR drive):
12 V DC 15%
DA
Direct current:
4 to 20 mA DC
C
RS-232C
Serial
communication
C5
RS-485
EA1
4 to 20 mA DC
External setting
input
EA2
0 to 20 mA DC
EV1
0 to 1 V DC
EV2
1 to 5 V DC
TA1
4 to 20 mA DC
Transmission
output
TV1
0 to 1 V DC
P
Insulated power output
(*1) 13 types of alarm action (including No event) and Energized/De-energized, Timer
output, Heater burnout alarm output option, Loop break alarm output, Time signal
output, Output during AT or Pattern end output can be selected by front keypad.
(*2) An input type can be selected by front keypad from; Thermocouple, RTD, Direct
current and Voltage.
(*3) Power supply voltage 100 to 240 V AC is standard. When ordering 24 V AC/DC,
enter “1” after the input code.
(*4) The rated current 20 A and 100 A for single-phase and 3-phase can be selected by
front keypad.
