Shinko BCD2R User Manual

10
5.3 Main setting mode
Sets SV, A1 and A2 value.
To enter Main setting mode, press the and keys (in that order) together in PV/SV Display Mode.
Use the or key for settings (or selections).
To register the set data, use the key..
Character Name, Function, Setting range Default value
SV 0
• Sets SV (desired value).
• Setting range: Scaling low limit to Scaling high limit
A1 value 0
• Sets the action point of Alarm 1 (A1) output.
• Not available if No alarm is selected in [A1 type].
• Setting range: Refer to (Table 5.3-1).
A2 value 0
• Sets the action point of Alarm 2 (A2) output.
• Not available if No alarm is selected in [A2 type], or the EV2 option is not ordered.
• Setting range: Refer to (Table 5.3-1).
(Table 5.3-1)
Alarm type Setting range
High limit alarm – (Input span) to input span ( ) *1
Low limit alarm – (Input span) to input span ( ) *1
High/Low limits alarm 0 to input span ( ) *1
High/Low limit range alarm 0 to input span ( ) *1
Process high alarm Input range low limit value to input range high limit value *2
Process low alarm Input range low limit value to input range high limit value *2
High limit alarm with standby – (Input span) to input span ( ) *1
Low limit alarm with standby – (Input span) to input span ( ) *1
High/Low limits alarm with standby 0 to input span ( ) *1
• When input has a decimal point, the negative low limit value is –199.9, and the positive high limit
value is 999.9.
• All alarm actions except process alarm are deviation setting from the SV (desired value).
*1: For DC input, the input span is the same as the scaling span.
*2: For DC input, input range low (or high) limit value is the same as scaling low (or high) limit value.
5.4 Sub setting mode
Sets Set value lock, Sensor correction, Communication parameters (when C5 option is ordered), etc.
To enter Sub setting mode, press and hold the and keys (in that order) together for 3 seconds in
PV/SV Display Mode.
Use the or key for settings (or selections).
To register the set data, use the key.
Character Name, Function, Setting range Default value
Set value lock Unlock
• Locks the set values to prevent setting errors.
The setting item to be locked depends on the selection.
• Selection range:
(Unlock): All set values can be changed.
(Lock 1): None of the set values can be changed.
(Lock 2): Only SV (desired value) can be changed.
(Lock 3): All set values can be changed.
However, do not change any setting item in the Setup mode.
Changed values revert to their previous value after power is turned
off because they are not saved in the non-volatile memory.
Sensor correction 0.0
• Sets the correction value for the sensor.
(Effective within the input rating value regardless of the sensor correction value)
PV= Current actual temperature + Sensor correction value
• Setting range: –100.0 to 100.0 ( )
DC input: -1000 to 1000
