8. Specifications
8.1 Standard specifications
Mounting: Flush
Setting: Input system using membrane sheet key
Display PV Display: Red LED 4 digits, character size 24 x 11 mm (H x W)
SV Display: Green LED 4 digits, character size 14 x 7 mm (H x W)
Accuracy (Setting and Indication):
Thermocouple: Within 0.2% of each input span 1 digit, or within 2 (4 ),
whichever is greater
However R, S inputs, 0 to 200 (32 to 392 ): Within 6 (12 )
B input, 0 to 300 (0 to 572 ): Accuracy is not guaranteed.
K, J, E, T, N inputs, less than 0 (32 ): Within 0.4% of input span 1 digit
RTD: Within 0.1% of each input span 1 digit, or
within 1 (2 ), whichever is greater
Direct current: Within 0.2% of each input span 1 digit
DC voltage: Within 0.2% of each input span 1 digit
Input sampling period: 0.25 seconds
Input Thermocouple: K, J, R, S, B, E, T, N, PL- , C(W/Re5-26), External resistance, 100 or less
(However, B input: External resistance, 40 or less)
RTD: Pt100, JPt100, 3-wire type
Allowable input lead wire resistance (10 or less per wire)
Direct current: 0 to 20 mA DC, 4 to 20 mA DC
Input impedance: 50
Allowable input current: 50 mA or less
Built-in shunt resistor (50 )
DC voltage: 0 to 1 V DC:
Input impedance: 1 M or more
Allowable input voltage: 5 V or less
Allowable signal source resistance: 2 k or less
0 to 5 V DC, 1 to 5 V DC, 0 to 10 V DC:
Input impedance: 100 k or more
Allowable input voltage: 15 V or less
Allowable signal source resistance: 100 or less
OUT1 (Limit control output)
Relay contact 1a, Control capacity: 3 A 250 V AC (resistive load)
1 A 250 V AC (inductive load cos =0.4)
Electrical life: 100,000 cycles
Minimum applicable load: 10 mA 5 V DC
A1 output
Action: ON/OFF action
Hysteresis: 0.1 to 100.0 ( ), 1 to 1000 (DC input) (Default: 1.0 )
Output: Relay contact 1a
Control capacity: 3 A 250 V AC (resistive load)
1 A 250 V AC (inductive load cos =0.4)
Electrical life: 100,000 cycles
Minimum applicable load: 10 mA 5 V DC
Control action
High limit control action, Low limit control action
OUT1 (Limit control output) hysteresis: 0.1 to 100.0 ( ), or 1 to 1000 (DC input)
