1. Model
1.1 Model
BCD2 R 0 -
OUT1 R Limit control output (Relay contact: 1a)
0 100 to 240 V AC (Standard)Power supply
voltage
1 24 V AC/DC
Input 0 Multi-range (*1)
0 No option 1 needed.
1 EV2 A2 output (Alarm type can be selected by keypad) (*2)
0 No option 2 needed.
Option
6 C5 Serial communication (RS-485)
(*1) Thermocouple, RTD, Direct current and DC voltage can be selected by keypad.
(*2) Alarm actions (9 types and No alarm action) and Energized/De-energized can be selected by keypad.
1.2 How to read the model label
Model labels are attached to the case and the inner assembly.
Model
Multi-range input
Supply voltage,
Power consumption
Custom order No.
O1 (OUT1), A1 output
Option
RoHS directive compliant
Manufacturer
Serial number
A2 output
Safety standard
