-4-
Model W1849 (For Machines Mfd. Since 11/16)
INTRODUCTION
Model W1849 Machine Specifications, Page 2 of 2
Blade Information
Standard Blade Length................................................................................. 120 in.
Blade Width Range.............................................................................. 1/8 – 3/4 in.
Type of Blade Guides...................................................... "Euro Style" Roller‐Disc Guides
Guide Post Adjustment Type.............................................................. Rack‐and‐Pinion
Has Quick‐Release.......................................................................................... Yes
Table Information
Table Length......................................................................................... 21‐3/4 in.
Table Width.......................................................................................... 16‐1/8 in.
Table Thickness....................................................................................... 1‐1/2 in.
Table Tilt............................................................................... Left 5, Right 45 Deg.
Table Tilt Adjustment Type............................................................... Rack‐and‐Pinion
Floor‐to‐Table Height................................................................................... 37 in.
Fence Locking Position.................................................................................. Front
Fence is Adjustable for Blade Lead...................................................................... Yes
Resaw Fence Attachment Included......................................................................
Yes
Miter Gauge Included.......................................................................................
No
Construction Materials
Table................................................................................................... Cast Iron
Trunnion.................................................................................................... Steel
Fence..................................................................................... Extruded Aluminum
Base/Stand................................................................................................. Steel
Frame/Body................................................................................................ Steel
Wheels................................................................................................. Cast Iron
Tire................................................................................................ Polyurethane
Wheel Cover .............................................................................................. Steel
Paint Type/Finish............................................................................. Powder Coated
Other Related Information
Wheel Diameter.......................................................................................... 14 in.
Wheel Width.......................................................................................... 1‐1/8 in.
Number of Dust Ports......................................................................................... 2
Dust Port Size.............................................................................................. 4 in.
Compatible Mobile Base............................................................................... D2057A
Other
Country of Origin ............................................................................................. Taiwan
Warranty ....................................................................................................... 2 Years
Approximate Assembly & Setup Time ...................................................................... 1 Hour
Serial Number Location .......................................................................... Machine ID Label
ISO 9001 Factory .................................................................................................. Yes
Features
14" Resaw Capacity
Equipped with Roller‐Disc ("Euro Style") Blade Guides
Optional Ball‐Bearing Blade Guides Available
Modular Blade Guide Design for Easy Changeovers Between Styles
Rack‐and‐Pinion Table Tilt Adjustments
Cast‐Iron Fence Base with 2‐Position Extruded‐Aluminum Fence
Storage Area for Extra Blades, Miter Gauge, and Blade Guide Assemblies When Not In Use
Cast‐Iron Wheels and Steel Table Trunnion
Blade Tension Indicator with Window in Wheel Cover
