DMX addressing
Note: Disconnect the fixtures from the DMX controller before master/slave operating, otherwise data
collisions can occur and the fixtures will not work properly!
It’s necessary to insert the XLR termination plug (with 120 Ohm ) into the input of the master fixture and
into the output of the last slave fixture in the data-link, in order to ensure proper transmission on the data
link.
From the master’s control panel it is possible to control any slave in a master/slave chain.
1) Press the Mode button, until the display shows Run. Then press enter.
2) Press the Up/Down button until the display shows DCNO and then press Enter. The first device should be
set to ADDR A001.
DMX Protocol
Channel 1 - Horizontal movement (Pan)
Push the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 530°and stopped at any position you wish.
Channel 2 - Vertical movement (Tilt)
Push the slider, up in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 280°and stopped at any position you wish.
Channel 3 - Pan fine 16 bit
Channel 4 - Tilt fine 16 bit
Channel 5 –PAN/TILT Speed
0-255 From Max Speed (0) to Min. Speed (255) in vector mode
Channel 6 – Lamp ON OFF & Reset
Channel 7 – Colours
Linear color change following the movement of the slider. In this way you can stop the color-wheel in any
position – also between two colors creating double-colored beams. Between 128 - 255, the color-wheel
rotates continuously the so-called “Rainbow” effect.
0-15 Open / White
16-31 Red
32-47 Yellow
48-63 Magenta
64-79 Green
80-95 Orange
96-111 Blue
112-127 Pink
128-255 Forwards rainbow effect from fast to slow
0-127 No Function
128-139 Lamp on after 3 seconds, Reset
140-229 No Function
230-239 Lamp off after 3 seconds
240-255 No Function
