SHOWTEC PHANTOM 65 V1 - Product Specifications

26
Ordercode: 40070
Phantom 65
Product Specifications
Model:
Showtec Phantom 65
Input voltage:
100-240V AC, 50/60Hz
Power consumption:
125W (full output)
DMX linking:
30pcs
Fuse:
F3AL/250V
Dimensions:
230 x 200 x 365 mm (LxWxH)
Weight:
6,2 kg
Operating and Programming:
Signal pin OUT:
Pin 1 (earth), pin 2 (-), pin 3 (+)
DMX Mode:
8, 13 channels
Signal input:
3-pin XLR IN
Signal output:
3-pin XLR OUT
Electro-mechanical effects:
Light source:
1 x 65W White LED
Light output:
1870 Lux @ 5 m
Focus:
Manual
Beam angle:
16º
Dimmer:
0-100%
Strobe:
0-20Hz
Housing:
Metal & flame-retardant plastic
DMX control:
via standard DMX controller
Onboard:
LCD display for easy setup
User-selectable Pan range:
540°/360°/180°
User-selectable Tilt range:
270°/180°/90°
Special:
Pan/Tilt movement blackout
Reverse Pan/Tilt movement
Pan/Tilt resolution:
16 bit
Color wheel:
8 dichroic colors + white
Color functions:
Rainbow-flow effect, split colors, bi-directional rotation
Rotating gobo wheel:
6 metal gobos + 1 glass gobo
Gobo functions:
Gobo-flow effect, Gobo shake
Control:
Stand alone, Manual, Sound-controlled, Master/Slave,
DMX-512
Prism:
3-facet prism
Connections:
3-pin XLR IN/OUT, Pro power connector IN/OUT
Cooling:
Cooling fan
Max. ambient temperature t
a
:
40°C
Max. housing temperature t
B
:
70°C
Minimum distance:
Minimum distance from flammable surfaces:
0,5 m
Minimum distance to lighted object:
1 m
Design and product specifications are subject to change without prior notice.
