SHOWTEC PHANTOM 65 V1 - Description of the Device; Features; Frontside

6
Ordercode: 40070
Phantom 65
Description of the device
Features
The Phantom 65 is a moving head with high output and great effects.
• Input voltage: 100-240V AC, 50/60Hz
• Power consumption: 125W
• Light source: 1 x 65W White LED
• Light output: 1870 Lux @ 5 m
• Dimmer: 0-100%
• Strobe: 0-20Hz
• Beam angle: 16°
• Focus: Manual focus
• DMX control: via standard DMX controller
• DMX channels: 8, 13 channels
• Built-in automatic programs + built-in sound-activated programs
• Reverse Pan / Tilt movement
• Special: Pan / Tilt movement blackout
• Pan 0º -- 540º, Tilt 0º -- 270º
• Pan/Tilt resolution: 16 bit
• Control: Stand alone, Manual, Sound-controlled, Master/Slave, DMX-512
• Color wheel: 8 dichroic colors + white
• Rotating gobo wheel: 6 metal gobos + 1 glass gobo
• Color functions: Split colors, Rainbow-flow effect
• Gobo functions: Gobo-flow effect, Gobo shake
• Rotation: Bi-directional
• Prism: 3-facet prism
• Housing: Metal & flame-retardant plastic
• Connection: 3-pin XLR IN/OUT, Pro power connector IN/OUT
• Fuse: F3AL/250V
• Dimensions: 230 x 200 x 365 mm (LxWxH)
• Weight: 6,2 kg
Frontside
Fig. 01
01) 1 x 65W White LED
02) LCD display + control buttons
