Shure Incorporated
27/40
1.
2.
Auditioning Mixes
Enter CueMode from the UTILITIES menu.
Use the ▼▲ buttons to scroll through your CueMode list to hear the mixes.
Exiting CueMode
Exit CueMode by pressing enter and selecting EXIT CUEMODE.
Managing CueMode Mixes
While in Cue Mode, you can access the following menu by pressing enter:
REPLACE MIX
Select and press sync on a rack unit to upload new data for the current mix (for example, if you have changed the trans
mitter frequency).
DELETE MIX
Removes the selected mix.
DELETE ALL
Removes all mixes.
EXIT CUEMODE
Exits CueMode and returns the bodypack to the previous frequency setting.
Frequency Scan
Use a frequency scan to analyze the RF environment for interference and identify available frequencies. There are three types
of scan:
Channel Scan Press the scan button on the bodypack. Finds the first available channel.
Group Scan Press and hold the scan button for two seconds. Finds the group with the greatest number of available chan
nels. (Each group contains a set of frequencies that are compatible when operating multiple systems in the same environ
ment.)
Full Scan From the bodypack menu select RADIO > FULL
SCAN. Press RUN SCAN to initiate a full scan. Press SPEC
TRUM to view full results in a graphical display.
Note: When performing a frequency scan:
Turn off the RF on the transmitters for the systems you are setting up. (This prevents them from interfering with the fre
quency scan.)
Turn on potential sources of interference such as other wireless systems or devices, computers, CD players, large LED
panels, effects processors, and digital rack equipment so they are operating as they would be during the presentation or
performance (so the scan will detect and avoid any interference they generate).
