8
Shure SLX Wireless
Single System Setup
Note: transmitting devices such as cellular phones and two-way radios may interfere with
wireless audio transmissions. Keep your SLX transmitters and receivers away from these and
other potential sources of interference.
Follow these steps when using a single SLX system:
1. Automatic Frequency Selection
Scans for an available channel and sets the receiver to that channel.
2. Automatic Transmitter Setup
Turn On the transmitter.
Open the transmitter battery compartment to display the infrared (IR) port
(see page 6 and page 7).
With the IR port exposed to the receiver, press sync.
Hold the sync button until the red light stops flashing on both receiver and transmitter.
When the receiver ready light glows, the system is ready for use.
Close the transmitter battery compartment.
Multiple System Setup
Follow these steps when using multiple SLX systems in a single installation:
1. Turn all receivers on and all transmitters off.
2. Set all receivers to the same frequency group (see “Group Selection” on page 9).
3. Perform Automatic Frequency Selection from the Single System Setup section
above.
4. Turn on the first transmitter.
5. Perform Automatic Transmitter Setup from the Single System Setup section above.
Repeat for each system.
Be sure that only one transmitter’s IR port is exposed when synchronizing a system.
menu select
888.888
GROUP
CHANNEL
AUTO
CHANNEL
SELECT
GROUP
SELECT
MANUAL
CHANNEL
SELECT
DISPLAY
FREQUENCY
SELECT
EXIT
MASTER
LIST
ANTENNA
A
B
MASTER LIST
MHz
LOW BATT
sync
< 15 cm (8 in.)
or
To Next Page
