SLX Programming
Any option displayed on screen will generally “time out” after five seconds.
SLX4 Receiver Programming
Group Selection
Allows manual selection of a frequency group. Pressing select increases the group number
by one. When the correct frequency is displayed, either wait five seconds for the screen to time
out, or press sync. For best results when operating multiple systems, set all systems to a single
group; then set each system to a unique channel within that group.
For more information on frequency groups and channels, see “Frequency Band Selection” on
page 2.
Manual Channel Selection
Allows manual selection of a frequency channel. Pressing select increases the channel num-
ber by one.When the correct frequency is displayed, either wait five seconds for the screen to
time out, or press sync.
Display Frequency
Displays the current frequency in MHz for approximately 5 seconds. Press and hold to in-
crease display length.
Lock or Unlock Receiver Settings
Hold down the select key and press menu to lock or unlock the receiver. When locked, the
current receiver settings cannot be changed.
Antenna Status
Indicates RF activity. Only one antenna is active at any one time.
Transmitter Battery Status
Indicates a low transmitter battery charge.
Full Group Warning
The FULL warning indicates that all available channels in the currently selected group are in
use. When this occurs, reprogram all systems to an alternate group.
Press either the menu or select button to exit the warning screen.
2x
menu select sync

888.888
GROUP
CHANNEL
AUTO
CHANNEL
SELECT
GROUP
SELECT
MANUAL
CHANNEL
SELECT
DISPLAY
FREQUENCY
SELECT
EXIT
MASTER
LIST
ANTENNA
A
B
MASTER LIST
MHz
LOW BATT
3x
menu select sync

888.888
GROUP
CHANNEL
AUTO
CHANNEL
SELECT
GROUP
SELECT
MANUAL
CHANNEL
SELECT
DISPLAY
FREQUENCY
SELECT
EXIT
MASTER
LIST
ANTENNA
A
B
MASTER LIST
MHz
LOW BATT
4x
menu select

888.888
GROUP
CHANNEL
AUTO
CHANNEL
SELECT
GROUP
SELECT
MANUAL
CHANNEL
SELECT
DISPLAY
FREQUENCY
SELECT
EXIT
MASTER
LIST
ANTENNA
A
B
MASTER LIST
MHz
LOW BATT
menuselect
+
888.888
GROUP
CHANNEL
AUTO
CHANNEL
SELECT
GROUP
SELECT
MANUAL
CHANNEL
SELECT
DISPLAY
FREQUENCY
SELECT
EXIT
MASTER
LIST
ANTENNA
A
B
MASTER LIST
MHz
LOW BATT
888.888
GROUP
CHANNEL
AUTO
CHANNEL
SELECT
GROUP
SELECT
MANUAL
CHANNEL
SELECT
DISPLAY
FREQUENCY
SELECT
EXIT
MASTER
LIST
ANTENNA
A
B
MASTER LIST
MHz
LOW BATT
888.888
GROUP
CHANNEL
AUTO
CHANNEL
SELECT
GROUP
SELECT
MANUAL
CHANNEL
SELECT
DISPLAY
FREQUENCY
SELECT
EXIT
MASTER
LIST
ANTENNA
A
B
MASTER LIST
MHz
LOW BATT
FULL
GROUP
CHANNEL
AUTO
CHANNEL
SELECT
GROUP
SELECT
MANUAL
CHANNEL
SELECT
DISPLAY
FREQUENCY
SELECT
EXIT
MASTER
LIST
ANTENNA
A
B
MASTER LIST
MHz
LOW BATT

Shure SLX Specifications

General

Operating Range	100 m (300 ft), typical
Dynamic Range	>100 dB
Total Harmonic Distortion	<0.5%, typical
RF Output Power	10 mW (region dependent)
Receiver Outputs	XLR and 1/4"
Transmitter Type	Handheld or Bodypack
Microphone Capsule (Handheld)	Shure SM58 or Beta 58A (depending on model)
Power Supply	Transmitter: Batteries
Modulation	FM
Signal-to-Noise Ratio	>100 dB
Weight (Transmitter)	Handheld: 290 g
Frequency Range	470-952 MHz (region dependent)
