13
English
Specifications
System
Frequency Range and Transmitter Output Level
NOTE: This Radio apparatus may be capable of
operating on some frequencies not authorized in your
region. Please contact your national authority to obtain
information on authorized frequencies for wireless
microphone products in your region.
Operating Range Under Typical Conditions
100m (300 ft.)
Note: actual range depends on RF signal absorption,
reflection, and interference
Audio Frequency Response (+/– 2 dB)
Minimum: 45 Hz
Maximum: 15 kHz
(Overall system frequency depends on
microphone element.)
Total Harmonic Distortion (ref. +/– 38 kHz deviation,
1kHz tone)
0.5%, typical
Dynamic Range
>100 dB A-weighted
Operating Temperature Range
–18°C (0°F) to +57°C (+135°F)
Note: battery characteristics may limit this range
Transmitter Audio Polarity
Positive pressure on microphone diaphragm (or positive
voltage applied to tip of WA302 phone plug) produces
positive voltage on pin 2 (with respect to pin 3 of low
impedance output) and the tip of the high impedance
1/4-inch output.
SLX1 Bodypack Transmitter
Audio Input Level
-10 dBV maximum at mic gain position
+10 dBV maximum at 0 dB gain position
+20 dBV maximum at -10 dB gain position
Gain Adjustment Range
30dB
Input Impedance
1 MΩ
RF Transmitter Output
30 mW maximum (dependent on applicable country
regulations)
Dimensions
108 mm H x 64 mm W x 19 mm D (4.25 x 2.50 x
0.75 in.)
Weight
81 grams (3 oz.) without batteries
Housing
Molded ABS case
Power Requirements
2 “AA” size alkaline or rechargeable batteries
Battery Life
>8 hours (alkaline)
SLX2 Handheld Transmitter
Audio Input Level
+2 dBV maximum at -10dB position
-8 dBV maximum at 0dB position
Gain Adjustment Range
10dB
RF Transmitter Output
30 mW maximum (dependent on applicable country
regulations)
Dimensions (including SM58 cartridge)
254 mm x 51 mm dia. (10 x 2 in.)
Weight
290 grams (10.2 oz.) without batteries
Housing
Molded PC/ABS handle and battery cup
Power Requirements
2 “AA” size alkaline or rechargeable batteries
Battery Life
>8 hours (alkaline)
SLX4 Receiver
Dimensions
42 mm H x 197 mm W x 134 mm D (1.65 x 7.76 x
5.28 in.)
Weight
816 g (1 lb. 13 oz.)
Housing
Galvanized steel
Audio Output Level (ref. +/– 38 kHz deviation with 1 kHz
tone)
XLR connector (into 600 Ω load): –13 dBV
1/4 inch connector (into 3000 Ω load): –2 dBV
Output Impedance
XLR connector: 200 Ω
1/4 inch connector: 1kΩ
XLR output
Impedance balanced
Pin 1: Ground (cable shield)
Pin 2: Audio
Pin 3: No Audio
Sensitivity
–105 dBm for 12 dB SINAD, typical
Image Rejection
>70 dB, typical
Power Requirements
12–18 Vdc at 150 mA, supplied by external power
supply
Band Range Transmitter output
H5
518–542 MHz 30 mW
J3
572–596 MHz 30 mW
L4
638–662 MHz 30 mW
P4
702–726 MHz 30 mW
R13
794-806 MHz 20 mW
R5
800–820 MHz 20 mW
S6
838–865 MHz 10 mW
JB
806–810 MHz 10 mW
Q4
740–752 MHz 10 mW
