- 51 -
IDE Secondary Slave
Options are in its sub menu.
Press <Enter> to enter the sub-menu of detailed options.
Drive A/Drive B
Select the type of floppy disk drive installed in your system.
Ø The choice: None, 360K, 5.25 in, 1.2M, 5.25 in, 720K, 3.5 in,
1.44M, 3.5 in, or 2.88M, 3.5 in
Video
Select the default video device.
Ø The choice: EGA/VGA, CGA 40, CGA 80, or MONO
Halt On
Select the situation in which you want the BIOS to stop the POST
process and notify you.
Ø The choice: All Errors, No Errors, All, But Keyboard, All, But
Diskette, or All, But Disk/Key
Base Memory
Displays the amount of conventional memory detected during boot up.
Ø The choice: N/A
Extended Memory
Displays the amount of extended memory detected during boot up.
Ø The choice: N/A
Total Memory
Displays the total memory available in the system.
Ø The choice: N/A
