5 Mounting
5.1 Safety
Important information
DANGER
H
azard due to lack of effectiveness of the protective device
If unsuitable brackets are used or if subjected to excessive vibrations, the device may
become detached or damaged.
Persons and parts of the body to be protected may not be recognized in case of
non-observance.
b
Only use SICK-approved brackets for mounting.
b
Take appropriate measures for vibration damping if vibration and shock specifica‐
tions exceed the values and test conditions specified in the data sheet.
NOTE
Mount t
he device in the following order.
Prerequisites
T
he safety light curtain has been designed correctly.
Further topics
•
"D
esign", page 21
•
"Technical data", page 79
5.2 Unpacking
Approach
1.
Check the components for completeness and the integrity of all parts.
2. In the event of complaints, contact the responsible SICK subsidiary.
Further topics
•
"Or
dering information", page 85
5.3 Mounting the system plug
Overview
Y
ou must mount the system plug on the safety light curtain prior to starting mounting
and electrical installation work. Please note that depending on the application, the
system plug used at the sender may be different to that at the receiver.
Important information
DANGER
H
azard due to lack of effectiveness of the protective device
Malfunctions can occur if the safety light curtain is connected other than with one of
the system plugs provided.
b
Use the system plugs provided.
MOUNTING 5
8027140/2021-11-04 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4
39
Subject to change without notice
