Chapter 4 Operating Instructions
CLV62x Bar Code Scanner
24 © SICK AG · Division Auto Ident · Germany · All rights reserved 8011965/S345/2008-04-16
Product description
4.3 Device versions
The CLV62x Bar Code Scanner with a glass reading window is available in the following ver-
sions, among others:
Tab. 4-2: Variants of the CLV62x Bar Code Scanner
Important Depending on the connection (design), the following interfaces are available:
• Standard version (cable with connector)
– RS-232, RS-422/485, CAN, two digital switching inputs, two digital switching out-
puts, power supply
• Ethernet version (revolving connector unit)
– Connector 1: Ethernet
– Connector 2: RS-232, RS-422/485, CAN, one digital switching input, power supply
Order no. Type Scanning method Reading
window
Connection (design)
CLV620: Mid-range reading range
1040288 CLV620-0000 Line scanner On front Cable with connector
1041547 CLV620-0120 Line scanner On front Connector unit on device
1041548 CLV620-1000 Raster scanner On front Cable with connector
1041549 CLV620-1120 Raster scanner On front Connector unit on device
1041550 CLV620-2000 Line scanner On side Cable with connector
1041551 CLV620-2120 Line scanner On side Connector unit on device
1041552 CLV620-3000 Raster scanner On side Cable with connector
1041553 CLV620-3120 Raster scanner On side Connector unit on device
CLV621: Long-range reading range
1041784 CLV621-0000 Line scanner On front Cable with connector
1041785 CLV621-0120 Line scanner On front Connector unit on device
1041786 CLV621-1000 Raster scanner On front Cable with connector
1041787 CLV621-1120 Raster scanner On front Connector unit on device
1041788 CLV621-2000 Line scanner On side Cable with connector
1041789 CLV621-2120 Line scanner On side Connector unit on device
1041790 CLV621-3000 Raster scanner On side Cable with connector
1041791 CLV621-3120 Raster scanner On side Connector unit on device
CLV622: Short-range reading range
1041792 CLV622-0000 Line scanner On front Cable with connector
1041793 CLV622-0120 Line scanner On front Connector unit on device
1041794 CLV622-1000 Raster scanner On front Cable with connector
1041795 CLV622-1120 Raster scanner On front Connector unit on device
1041796 CLV622-2000 Line scanner On side Cable with connector
1041797 CLV622-2120 Line scanner On side Connector unit on device
1041798 CLV622-3000 Raster scanner On side Cable with connector
1041799 CLV622-3120 Raster scanner On side Connector unit on device
