Deflection range in mm (inch) 1
–300
(–11.81)
600
(23.62)
40°
20°
700
(27.56)
c
b
a
Resolution 3
a: 0.35 mm (13.8 mil)
c: 1.0 mm (39.5 mil)
b: 0.50 mm (19.7 mil)
Reading distance in mm (inch) 2
–100
(–3.94)
0
0
400
(15.75)
–200
(–7.87)
200
(7.87)
400
(15.75)
500
(19.69)
–100
(–3.94)
300
(11.81)
100
(3.94)
300
(11.81)
–200
(–7.87)
100
(3.94)
200
(7.87)
Figure 66: Oscillating mirror deflection widths diagram CLV640, standard density, focus position
280 mm, oscillating mirror
1
Deflection width in mm (inch)
2
Reading distance in mm (inch)
3
Solution
